4 Reassembly
After replacing a part being listed in Replacements, the instruction of that section usually ends by
directing you to this Reassembly section with a specification of the instructions you have to carry out
in order to reassemble the phone.
4.1 Overview
The reassembly is done in the following sequence:
1. Keyboard FPC Assembly 11. Screw
Cover Coated
2. Dome Foil 12. Battery (a)
3. Keyboard Battery Cover
Assembly (b)
4. Top Rear Inner Panel Assy
5. Sliding Lens Cover
6. Card Reader Assembly
7. PBA
8. Speakerbox Assembly
9.
ntenna Cover Assembl
Start
Done
