3.8 Plastic Slider Snap
Follow the 2.1.1 – 2.1.4 & 2.1.8 Disassembly instructions!
Remove the Plastic Slider Snap as described in 2.1.8
Install the Plastic Slider Snap as described in 4.1.5.
Follow the 4.1.5 & 4.1.9 – 4.1.12 Reassembly instructions!
3.9 Top Rear Inner Panel Assy
Follow the Follow the 2.1.1 – 2.1.6 & 2.1.8 - 2.1.9 Disassembly instructions!
ITP
SW AND FLASH LED CALIBRATION IS NEEDED IN THIS PROCEDURE!
Prepare the new Top Rear Inner Panel Assy.
Follow the 4.1.4 – 4.1.5 & 4.1.7 - 4.1.12 Reassembly instructions!
Perform a Flash LED calibration according to chapter 3.3 in Test Instructions, Electrical 1212-7767.
3.10 Keyboard
Follow the 2.1.3 & 2.1.10 Disassembly instructions!
Prepare the new Keyboard.
Follow the 4.1.3 & 4.1.10 Reassembly instructions!
3.11 Dome Foil
Follow the 2.1.3 & 2.1.10 – 2.1.11 Disassembly instructions!
Prepare the new Dome Foil.
Follow the 4.1.2 – 4.1.3 & 4.1.10 Reassembly instructions!
3.12 Keyboard FPC Assembly
Follow the 2.1.1 – 2.1.6 & 2.1.10 – 2.1.12 Disassembly instructions!
Prepare the new Keyboard FPC Assembly.
Follow the 4.1.1 – 4.1.3 & 4.1.7 – 4.1.12 Reassembly instructions!
3.13 Gasket for Keyboard BtB
Follow the 2.1.1 – 2.1.6 & 2.1.10 – 2.1.11 Disassembly instructions!
Remove the Gasket for Keyboard BtB as described in 2.1.12.
Install the new Gasket for Keyboard BtB as described in 4.1.1.
Follow the 4.1.2 – 4.1.3 & 4.1.7 – 4.1.12 Reassembly instructions!
3.14 Foil Adhesive Double Side 0.0 mm Adhesive
Keyboard Flex
Follow the 2.1.1 – 2.1.6 & 2.1.10 – 2.1.11 Disassembly instructions!
Remove the Foil Adhesive Double Side 0.0 mm Adhesive Keyboard Flex as described in 2.1.12.
Install the new Foil Adhesive Double Side 0.0 mm Adhesive Keyboard Flex as described in 4.1.1.
Follow the 4.1.2 – 4.1.3 & 4.1.7 – 4.1.12 Reassembly instructions!
