Working Instruction Repair Instruction Mechanical/,
Mechanical
1212-7760 State: Preliminary 8.1
Company Internal
© Sony Ericsson Mobile Communications AB
41(66)
3.24 BT Antenna
REMOVAL
Follow the 2.1.1 – 2.1.6 Disassembly instructions!
Use the Dentist Hook to remove the BT Antenna.
INSTALLATION
Position the new BT Antenna carefully and then attach it to
the Frame Assy.
Follow the 4.1.7 – 4.1.12 Reassembly instructions!
