Sony Ericsson C902 - Battery Cover Assembly & Battery; Screw Cover Coated; Co-Brand Label; Antenna Cover Assembly

Working Instruction Repair Instruction Mechanical/,
Mechanical
1212-7760 State: Preliminary 8.1
Company Internal
© Sony Ericsson Mobile Communications AB
27(66)
3.1 Battery Cover Assembly & Battery
Follow the 2.1.1 Disassembly instructions!
Prepare the new Battery Cover Assembly and/or Battery.
Follow the 4.1.12 Reassembly instructions!
3.2 Screw Cover Coated
Follow the 2.1.2 Disassembly instructions!
Prepare the new Coated Screw Cover(s).
Follow the 4.1.11 Reassembly instructions!
3.3 Co-Brand Label
Follow the 2.1.3 Disassembly instructions!
Prepare the new Co-Brand Label.
Follow the 4.1.10 Reassembly instructions!
3.4 Antenna Cover Assembly
Follow the 2.1.1 – 2.1.4 Disassembly instructions!
Prepare the new Antenna Cover Assembly.
Follow the 4.1.9 – 4.1.12 Reassembly instructions!
3.5 Speakerbox Assembly
Follow the 2.1.1 – 2.1.5 Disassembly instructions!
Prepare the new Speakerbox Assembly
Follow the 4.1.8 – 4.1.12 Reassembly instructions!
3.6 Card Reader Assembly
Follow the 2.1.1 – 2.1.7 Disassembly instructions!
Prepare the new Card Reader Assembly.
Follow the 4.1.6 – 4.1.12 Reassembly instructions!
3.7 Sliding Lens Cover
Follow the 2.1.1 – 2.1.4 & 2.1.8 Disassembly instructions!
Prepare the new Sliding Lens Cover.
Follow the 4.1.5 & 4.1.9 – 4.1.12 Reassembly instructions!
