Working Instruction Repair Instruction Mechanical/,
Mechanical
1212-7760 State: Preliminary 8.1
Company Internal
© Sony Ericsson Mobile Communications AB
51(66)
Keyboard FPC Assembly continued
Attach the Keyboard FPC Assembly to the Frame Assy.
Use the ESD tweezers to attach a new Gasket for Keyboard
BtB to the Keyboard FPC Assembly.
To Next Page
