Adding Edges to Keys
Chapter 5 Adjusting Wipes and Keys
1 When using the BKDF-901: Depending on the key to
which you want to add the edges, press one of the
KEY1 to KEY4 buttons in the KEY
DELEGATION block, lighting it.
When using the BKDF-902: Depending on the key to
which you want to add the edges, press one of the
KEY1 to KEY4 buttons in the key/AUX bus
control block, lighting it.
2 Press the EDGE SHADOW button in the KEYER
block, lighting it.
Edges (Shadows) are enabled, and the Edge Shadow
sub menu appears in the display panel.
Edge Shadow sub menu parameters
Use the sub menus of the Edge Shadow sub menu to do the
following.
To switch between sub menus, press the h and H
buttons in the numeric keypad.
Edge Type (Type) sub menu parameters
Edge Color (Color) sub menu parameters
Edge Position (Position) sub menu parameters
Sub menu Operation
Edge Type (Type) Select the edge type, and specify
properties such as the edge width
and softness.
Edge Color (Color) Adjust the edge color.
Edge Position (Position) Adjust the edge position.
Operation Knob Parameter Settings
Select the
edge type.
F1 Typ (Type) Normal: Normal
edges
Outline: Outline
Extrude: Drop
shadow
Shadow:
Shadow
Adjust the
edge width.
F2 Wid (Width) 1 to 8
Adjust the
edge softness
(amount of
blurring).
F3 Sft (Softness) 0.0 to 100.0
When Extrude
is selected,
specify the
edge
direction.
(Specify as a
position
corresponding
to a number
on the face of
an analog
clock.)
Example: 3
corresponds
to the
direction from
3 o’clock.
F4 Dir (Direction) 0 to 11
Operation Knob Parameter Settings
Adjust the
luminance of
the edges.
F2 Lum (Luminance) 0.0 to 108.6
Adjust the
saturation
(color density)
of the edges.
F3 Sat (Saturation) 0.0 to 100.0
Adjust the hue
of the edges.
F4 Hue 0.0 to 359.5
Operation Knob Parameter Settings
When Shadow
is selected,
specify the X
coordinate of
the position
where the
shadow is
added.
F2 PX (Position X) –100.0 to 100.0
When Shadow
is selected,
specify the Y
coordinate of
the position
where the
shadow is
added.
F3 PY (Position Y) –100.0 to 100.0
Operation Knob Parameter Settings
