207
Specifications
Appendix
Specifications
Design and specifications are subject to change without
notice.
DFS-900M Processor Unit
Signal processing
HD mode/SD mode
HD mode or SD mode can be selected
with a menu.
Television system
1080/59.94i, 1080/50i, 720/50p, 720/
59.94p
480/59.94i, 576/50i
Signal processing system
4:2:2:4 digital component
Quantization bits
Y: 10 bits, C: 10 bits, KEY: 10 bits
Input/output delay
1 H (when the frame synchronizer is
OFF)
Inputs/outputs
Video input BNC type (8), 800 mVp-p, 75 ohms
HD-SDI: 1.485 Gbps or 1.485/
1.001 Gbps
SD-SDI: 270 Mbps
The frame synchronizer function is built
in for all the inputs.
Reference input
BNC type (2), 75 ohms, loop-through
(An external 75-ohm terminator is
required.)
BB: NTSC 0.429 Vp-p, PAL 0.45 Vp-p
(Tri-level sync: ±0.3 Vp-p is available for
HD mode.)
Video output BNC type (4), 800 mVp-p, 75 ohms
HD-SDI: 1.485 Gbps or 1.485/
1.001 Gbps
SD-SDI: 270 Mbps
Reference output
BNC type, 75 ohms
BB: NTSC 0.429 Vp-p, PAL 0.45 Vp-p
(Tri-level sync: ±0.3 Vp-p is available for
HD mode.)
Interfaces
REMOTE D-sub 9-pin (3), female
EDITOR D-sub 9-pin, female
GPI IN D-sub 25-pin, female, 16 inputs
TALLY/GPI OUT
D-sub 37-pin, female, 32 outputs
30 V DC, 100 mA, open collector
PANEL RJ-45 type
General
Power requirements
100 to 240 V AC, 50/60 Hz
Power consumption
400 W (when the maximum number of
optional boards are installed)
Current consumption
5.7 to 2.5 A (100 to 240 V AC)
Peak inrush current
(1) Power ON, current probe method: 30
A (100 V), 80 A (240V)
(2) Hot switching inrush current,
measured in accordance with
European standard EN55103-1: 40 A
(230 V)
Operating temperature
5°C to 40°C (41°F to 104°F)
Dimensions (w/h/d)
430 × 132 × 445 mm (17 × 5
1
/
4
× 17
5
/
8
inches)
Mass Approx. 17.3 kg (38 lb 2.2 oz) (not
including any optional product and
accessory)
Supplied accessories
Control cable (shielded cross cable
complied with IEEE 802.3 Ethernet
100BASE-TX standards, for
connection between the Processor Unit
and Control Panel) (1)
Rack mounting bracket (1 set)
Operating Instructions (1)
Warranty (1)
Accessories not supplied
AC power cord (for USA and Canada):
125 V, 10 A, 2.4 m (7 feet 10
1
/
2
inches)
Part No. 1-551-812-31
AC power cord (for Europe): 250 V, 10
A, 2.5 m (8 feet 2
1
/
2
inches)
Part No. 1-782-929-12
BKDF-901 1M/E Control Panel
Interface
Operating panel
USB MEMORY
High Speed USB (USB2.0) Type-A
Rear panel
EXT DISPLAY
High density D-sub 15-pin, female
DEVICE High Speed USB (USB2.0) Type-A
PROCESSOR RJ-45
