Menu Structure
Appendix
Appendix
Menu Structure
The following menu tree shows the configuration of the switcher’s menu system
and lists the menu items that appear in the display panel. Names in parentheses
are the names that appear in GUI menu screens, which are displayed when you
connect an optional PC monitor or an optional touch panel monitor.
For more information about GUI menu screens, see “Menu Operations in the
GUI Menus” (page 64).
Transition Menu (for Transition, Wipe, and DME Settings)
Level 1 Level 2 Level 3 Level 4
Transition Rate (Rate) PGM (PGM Rate)
DSK (DSK Rate)
FTB (FTB Rate)
(Wipe) Wipe Pattern (Pattern) Pat (Pattern No.)
Wid (Border Width)
Soft (Border Softness)
Src (Border Source)
Wipe Border Color
(Border Color)
Pat (Pattern No.)
Lum (Luminance)
Sat (Saturation)
Hue (Hue)
Wipe Modify (Modify) Asp (Aspect)
PX (Center Position X)
PY (Center Position Y)
Ang (Angle)
User (User) Usr (User Pattern)
Usr Store (User Wipe Date Store)
(Continued) Usr Clear (User Wipe Date Clear)
To Next Page
