Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
63
HCD-DX50/RG80
R822 1-216-842-11 METAL CHIP 56K 5% 1/16W
R823 1-216-833-11 METAL CHIP 10K 5% 1/16W
R824 1-216-841-11 METAL CHIP 47K 5% 1/16W
R825 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R826 1-216-839-11 METAL CHIP 33K 5% 1/16W
R827 1-216-837-11 METAL CHIP 22K 5% 1/16W
R829 1-216-837-11 METAL CHIP 22K 5% 1/16W
R830 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R831 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R841 1-216-837-11 METAL CHIP 22K 5% 1/16W
R842 1-216-837-11 METAL CHIP 22K 5% 1/16W
R843 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
(E51)
R843 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
(EXCEPT DX50: E51)
R844 1-216-845-11 METAL CHIP 100K 5% 1/16W
R845 1-216-857-11 METAL CHIP 1M 5% 1/16W
R851 1-260-304-71 CARBON 10 5% 1/2W
(DX50: KR)
R852 1-260-304-71 CARBON 10 5% 1/2W
(DX50: KR)
R854 1-216-841-11 METAL CHIP 47K 5% 1/16W
R861 1-216-821-11 METAL CHIP 1K 5% 1/16W
R862 1-216-833-11 METAL CHIP 10K 5% 1/16W
R863 1-216-841-11 METAL CHIP 47K 5% 1/16W
R864 1-216-821-11 METAL CHIP 1K 5% 1/16W
R865 1-216-821-11 METAL CHIP 1K 5% 1/16W
R866 1-216-806-11 RES-CHIP 56 5% 1/16W
R868 1-215-891-11 METAL OXIDE 680 5% 2W
R869 1-215-891-11 METAL OXIDE 680 5% 2W
R891 1-216-833-11 METAL CHIP 10K 5% 1/16W
R892 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R893 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R895 1-216-864-11 SHORT 0
0 R901 1-249-405-11 CARBON 100 5% 1/4W F
R911 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R912 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R914 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R966 1-216-806-11 RES-CHIP 56 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB41 1-234-575-11 ENCAPSULATED COMPONENT
< VARIABLE RESISTOR >
RV11 1-241-765-11 RES, ADJ, CARBON 22K
RV301 1-241-764-11 RES, ADJ, CARBON 10K
RV302 1-241-762-11 RES, ADJ, CARBON 2.2K
RV303 1-241-762-11 RES, ADJ, CARBON 2.2K
RV304 1-241-768-11 RES, ADJ, CARBON 220K
RV351 1-241-764-11 RES, ADJ, CARBON 10K
RV354 1-241-768-11 RES, ADJ, CARBON 220K
< RELAY >
RY801 1-755-372-11 RELAY
< TRANSFORMER >
T11 1-435-792-11 TRANSFORMER, DISCRIMINATOR
T301 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
< TERMINAL >
TM1 1-694-555-21 TERMINAL BOARD (4P)(ANTENNA)
(EXCEPT DX50: KR)
TM1 1-694-556-12 TERMINAL BOARD (ANT.PAL)(ANTENNA)
(DX50: KR)
TM801 1-694-635-11 TERMINAL BOARD (4P)(SPEAKER)
< VIBRATOR >
X51 1-760-549-31 VIBRATOR, CRYSTAL 4.5MHz
X501 1-567-098-41 VIBRATOR, CRYSTAL 32.768kHz
X502 1-781-107-21 VIBRATOR, SERAMIC 16MHz
************************************************************
1-680-265-11 MAIN TRANS BOARD
*****************
1-533-217-31 HOLDER, FUSE
< CAPACITOR >
C941 1-128-553-11 ELECT 220uF 20.00% 63V
C977 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN977 1-564-526-11 PLUG, CONNECTOR 11P
< DIODE >
D977 8-719-024-99 DIODE 11ES2-NTA2B
< FUSE >
0 F971 1-533-473-11 FUSE, GLASS TUBE (DIA.5) (T6.3AL/250V)
(DX50: E,SP,AR,E51)
0 F974 1-533-454-11 FUSE, GLASS TUBE (DIA.5) (6.3A/125V) (RG80)
0 F974 1-533-473-11 FUSE, GLASS TUBE (DIA.5) (T6.3AL/250V)
(EXCEPT RG80)
0 F975 1-533-454-11 FUSE, GLASS TUBE (DIA.5) (6.3A/125V) (RG80)
0 F975 1-533-473-11 FUSE, GLASS TUBE (DIA.5) (T6.3AL/250V)
(EXCEPT RG80)
< RESISTOR >
0 R941 1-219-120-11 FUSIBLE 0.15 5% 1/4W
0 R944 1-249-389-11 CARBON 4.7 5% 1/4W F
0 R951 1-219-120-11 FUSIBLE 0.15 5% 1/4W
0 R952 1-219-120-11 FUSIBLE 0.15 5% 1/4W
0 R953 1-219-120-11 FUSIBLE 0.15 5% 1/4W
0 R954 1-202-725-00 SOLID 3.3M 10% 1/2W
(RG80)
************************************************************
1-675-910-14 MOTOR BOARD
************
< CAPACITOR >
C721 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
MAIN MAIN TRANS MOTOR
To Next Page
