Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
64
HCD-DX50/RG80
< CONNECTOR >
CN721 1-770-516-31 CONNECTOR, FFC 8P
CN722 1-785-330-11 PIN, CONNECTOR (LIGHT ANGLE)4P
< SWITCH >
S701 1-771-822-11 SWITCH, LEVER (SLIDE)
************************************************************
A-4475-778-A PAD SWITCH BOARD, COMPLETE (DX50)
*********************************
A-4476-977-A PAD SWITCH BOARD, COMPLETE (RG80)
*********************************
< CAPACITOR >
C751 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C752 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
< DIODE >
D751 8-719-063-93 DIODE SLR325VC-N-T32 (REC)
D752 8-719-063-93 DIODE SLR325VC-N-T32 (ENTER)
< TRANSISTOR >
Q751 8-729-900-80 TRANSISTOR BA1A4M-TP
Q752 8-729-900-80 TRANSISTOR BA1A4M-TP
< RESISTOR >
R750 1-249-410-11 CARBON 270 5% 1/4W F
R751 1-249-411-11 CARBON 330 5% 1/4W
R752 1-249-411-11 CARBON 330 5% 1/4W
R754 1-249-410-11 CARBON 270 5% 1/4W F
R755 1-249-413-11 CARBON 470 5% 1/4W F
R756 1-249-414-11 CARBON 560 5% 1/4W F
R757 1-249-416-11 CARBON 820 5% 1/4W F
R758 1-249-417-11 CARBON 1K 5% 1/4W F
R759 1-249-418-11 CARBON 1.2K 5% 1/4W F
R760 1-249-419-11 CARBON 1.5K 5% 1/4W F
R761 1-249-421-11 CARBON 2.2K 5% 1/4W F
R762 1-249-422-11 CARBON 2.7K 5% 1/4W F
R763 1-249-424-11 CARBON 3.9K 5% 1/4W F
R764 1-249-426-11 CARBON 5.6K 5% 1/4W
R765 1-249-428-11 CARBON 8.2K 5% 1/4W F
R766 1-249-431-11 CARBON 15K 5% 1/4W
R768 1-249-410-11 CARBON 270 5% 1/4W F
R769 1-249-413-11 CARBON 470 5% 1/4W F
R770 1-249-414-11 CARBON 560 5% 1/4W F
R771 1-249-416-11 CARBON 820 5% 1/4W F
R772 1-249-417-11 CARBON 1K 5% 1/4W F
R773 1-249-418-11 CARBON 1.2K 5% 1/4W F
R774 1-249-419-11 CARBON 1.5K 5% 1/4W F
R775 1-249-421-11 CARBON 2.2K 5% 1/4W F
R776 1-249-422-11 CARBON 2.7K 5% 1/4W F
R777 1-249-424-11 CARBON 3.9K 5% 1/4W F
R778 1-249-426-11 CARBON 5.6K 5% 1/4W
R779 1-249-428-11 CARBON 8.2K 5% 1/4W F
R780 1-249-431-11 CARBON 15K 5% 1/4W
R790 1-249-434-11 CARBON 27K 5% 1/4W
< SWITCH >
S751 1-476-504-11 ENCODER-ROTARY (VOLUME)
S752 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S753 1-762-875-21 SWITCH, KEYBOARD (B)
S754 1-762-875-21 SWITCH, KEYBOARD (b)
S755 1-762-875-21 SWITCH, KEYBOARD (SPECTRUM)
S756 1-762-875-21 SWITCH, KEYBOARD (EFECT ON/OFF)
S757 1-762-875-21 SWITCH, KEYBOARD (GAME EQ)
S758 1-762-875-21 SWITCH, KEYBOARD (KARAOKE PON)(DX50)
S760 1-762-875-21 SWITCH, KEYBOARD (m –)
S761 1-762-875-21 SWITCH, KEYBOARD (.)
S762 1-762-875-21 SWITCH, KEYBOARD (x)
S763 1-762-875-21 SWITCH, KEYBOARD (HI-DUB)
S764 1-762-875-21 SWITCH, KEYBOARD (REC)
S765 1-762-875-21 SWITCH, KEYBOARD (M +)
S768 1-762-875-21 SWITCH, KEYBOARD (PLAY MODE)
S769 1-762-875-21 SWITCH, KEYBOARD (REPEAT)
S770 1-762-875-21 SWITCH, KEYBOARD (EDIT)
S771 1-762-875-21 SWITCH, KEYBOARD (MUSIC EQ)
S772 1-762-875-21 SWITCH, KEYBOARD (MOVIE EQ)
S773 1-762-875-21 SWITCH, KEYBOARD (v)
S774 1-762-875-21 SWITCH, KEYBOARD (ENTER)
S775 1-762-875-21 SWITCH, KEYBOARD (V)
S776 1-762-875-21 SWITCH, KEYBOARD (P FILE)
S777 1-762-875-21 SWITCH, KEYBOARD (GROOVE)
S778 1-762-875-21 SWITCH, KEYBOARD (SURROUND)
S779 1-762-875-21 SWITCH, KEYBOARD (gG)
S780 1-762-875-21 SWITCH, KEYBOARD (X)
S781 1-762-875-21 SWITCH, KEYBOARD (>)
************************************************************
A-4475-773-A PANEL BOARD, COMPLETE (DX50)
****************************
A-4476-975-A PANEL BOARD, COMPLETE (RG80)
****************************
4-231-581-01 HOLDER FL
< CAPACITOR >
C603 1-162-286-31 CERAMIC 220PF 10.00% 50V
C604 1-124-257-00 ELECT 2.2uF 20% 50V
C605 1-162-286-31 CERAMIC 220PF 10.00% 50V
C606 1-124-257-00 ELECT 2.2uF 20% 50V
C607 1-126-157-11 ELECT 10uF 20% 16V
(DX50)
C608 1-126-157-11 ELECT 10uF 20% 16V
C609 1-162-303-11 CERAMIC 0.0033uF 30.00% 16V
C610 1-126-157-11 ELECT 10uF 20% 16V
C611 1-126-157-11 ELECT 10uF 20% 16V
C612 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C613 1-124-261-00 ELECT 10uF 20% 50V
C614 1-162-294-31 CERAMIC 0.001uF 10% 50V
C615 1-104-664-11 ELECT 47uF 20.00% 10V
C616 1-126-934-11 ELECT 220uF 20.00% 16V
C617 1-124-589-11 ELECT 47uF 20% 16V
C618 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C619 1-124-589-11 ELECT 47uF 20% 16V
C620 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C622 1-126-163-11 ELECT 4.7uF 20% 50V
C623 1-164-159-21 CERAMIC 0.1uF 50V
PAD SWITCH PANELMOTOR
To Next Page
