Sony HCD-DX50 - Page 67

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
65
HCD-DX50/RG80
C624 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C625 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C626 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C627 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C628 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C629 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C630 1-162-294-31 CERAMIC 0.001uF 10% 50V
C631 1-162-294-31 CERAMIC 0.001uF 10% 50V
C651 1-164-159-11 CERAMIC 0.1uF 50V
C652 1-126-960-11 ELECT 1uF 20.00% 50V
C653 1-126-960-11 ELECT 1uF 20.00% 50V
C717 1-124-584-00 ELECT 100uF 20% 10V
(DX50)
C718 1-124-584-00 ELECT 100uF 20% 10V
(DX50)
C719 1-124-257-00 ELECT 2.2uF 20% 50V
(DX50)
C736 1-124-261-00 ELECT 10uF 20% 50V
(DX50)
C737 1-124-261-00 ELECT 10uF 20% 50V
(DX50)
C738 1-124-257-00 ELECT 2.2uF 20% 50V
(DX50)
C739 1-162-215-31 CERAMIC 47PF 5% 50V
(DX50)
C740 1-162-282-31 CERAMIC 100PF 10% 50V
(DX50)
C741 1-124-463-00 ELECT 0.1uF 20% 50V
(DX50)
C742 1-162-215-31 CERAMIC 47PF 5% 50V
(DX50)
C743 1-162-290-31 CERAMIC 470PF 10% 50V
(DX50)
C744 1-162-294-31 CERAMIC 0.001uF 10% 50V
(DX50)
C747 1-126-961-11 ELECT 2.2uF 20.00% 50V
(DX50)
C748 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
(DX50)
C749 1-164-159-11 CERAMIC 0.1uF 50V
(DX50)
< CONNECTOR >
CN601 1-793-767-11 CONNECTOR, BOARD TO BOARD 30P
< DIODE >
D608 8-719-057-97 DIODE SEL5923A-TP15 (GAME)
D609 8-719-057-97 DIODE SEL5923A-TP15 (TUNER/BAND)
D610 8-719-109-85 DIODE MTZJ-T-77-5.1B
D611 8-719-991-33 DIODE 1SS133T-77
D612 8-719-057-97 DIODE SEL5923A-TP15 (TUNER/BAND)
D613 8-719-057-97 DIODE SEL5923A-TP15 (CD)
D614 8-719-057-97 DIODE SEL5923A-TP15 (CD)
D615 8-719-057-97 DIODE SEL5923A-TP15 (TAPE A/B)
D616 8-719-057-97 DIODE SEL5923A-TP15 (TAPE A/B)
D617 8-719-057-97 DIODE SEL5923A-TP15 (MD(VIDEO))
D618 8-719-057-97 DIODE SEL5923A-TP15 (MD(VIDEO))
< FILTER >
FL601 1-518-739-11 INDICATOR TUBE FLUORESCENT
< IC >
IC601 8-759-828-89 IC MB90M407PF-G-103-BND
IC602 8-759-570-21 IC BA3830F-E2
IC603 8-759-827-70 IC NJL64H400A-1 (g)
IC616 8-719-647-10 IC 2933
IC722 8-759-167-88 IC NJM4565D (DX50)
< JACK >
J601 1-793-724-11 JACK BLOCK, PIN 3P (INPUT(GAME)
J631 1-785-569-11 JACK (SMALL TYPE) (PHONES)
J722 1-785-569-11 JACK (SMALL TYPE) (MIC) (DX50)
< TRANSISTOR >
Q601 8-729-900-80 TRANSISTOR BA1A4M-TP
Q602 8-729-900-80 TRANSISTOR BA1A4M-TP
Q603 8-729-900-80 TRANSISTOR BA1A4M-TP
Q604 8-729-900-80 TRANSISTOR BA1A4M-TP
Q605 8-729-900-80 TRANSISTOR BA1A4M-TP
Q721 8-729-119-79 TRANSISTOR 2SC2785TP-FEK (DX50)
< RESISTOR >
R602 1-249-417-11 CARBON 1K 5% 1/4W F
R603 1-249-417-11 CARBON 1K 5% 1/4W F
R604 1-249-441-11 CARBON 100K 5% 1/4W
R605 1-249-441-11 CARBON 100K 5% 1/4W
R606 1-247-889-00 CARBON 270K 5% 1/4W
R607 1-247-889-00 CARBON 270K 5% 1/4W
R608 1-249-421-11 CARBON 2.2K 5% 1/4W F
R609 1-249-440-11 CARBON 82K 5% 1/4W
(DX50)
R610 1-249-441-11 CARBON 100K 5% 1/4W
(DX50)
R611 1-249-437-11 CARBON 47K 5% 1/4W
R612 1-249-435-11 CARBON 33K 5% 1/4W
R613 1-249-429-11 CARBON 10K 5% 1/4W
R614 1-249-435-11 CARBON 33K 5% 1/4W
R615 1-249-433-11 CARBON 22K 5% 1/4W
R616 1-249-429-11 CARBON 10K 5% 1/4W
(DX50)
R617 1-249-439-11 CARBON 68K 5% 1/4W
R618 1-249-429-11 CARBON 10K 5% 1/4W
R625 1-249-401-11 CARBON 47 5% 1/4W F
R626 1-249-404-00 CARBON 82 5% 1/4W F
R627 1-249-404-00 CARBON 82 5% 1/4W F
R628 1-249-404-00 CARBON 82 5% 1/4W F
R629 1-249-404-00 CARBON 82 5% 1/4W F
R630 1-249-409-11 CARBON 220 5% 1/4W F
R631 1-249-418-11 CARBON 1.2K 5% 1/4W F
R632 1-249-417-11 CARBON 1K 5% 1/4W F
R633 1-249-416-11 CARBON 820 5% 1/4W F
R634 1-249-414-11 CARBON 560 5% 1/4W F
R635 1-249-413-11 CARBON 470 5% 1/4W F
R636 1-249-410-11 CARBON 270 5% 1/4W F
R645 1-249-429-11 CARBON 10K 5% 1/4W
PANEL
