17
HCD-FX10
qg
sub chassis
qf
screw
(BVTP2.6
×
8)
8
step screw
qs
step screw
5
step screw
9
tension
spring
(slider 2)
6
tension spring
(slider 4)
0
rubber roller
(slider 4) assy
7
rubber roller
(slider 1) assy
qa
rubber roller
(slider 2) assy
qd
rubber roller
(slider 1) assy
3
tension spring
(base slider 5)
1
step screw
4
rubber roller
(slider 5) assy
2
rubber roller
(slider S) assy
bracket (top) assy
Note: Refer to assembly (Section 4)
2
gear (mode cam)
: Note
1
screw
(PTPWH2.6
×
8)
3
slider (mode cam) assy
5
two gears
(center)
7
two gears (center)
8
timing belt (rear)
9
timing belt (rear)
4
gear
(timing)
6
timing belt
(front)
timing belt
(rear)
When install three timing belts,
its pass under each claws.
timing belt
(rear)
timing belt (front)
claw
claw
claw
claw
3-16. RUBBER ROLLER (SLIDER) ASSY
3-17. TIMING BELT (FRONT/REAR)
