3535
HCD-FX10
HCD-FX10
6-4. PRINTED WIRING BOARD – DMB10 SECTION (SIDE A) –
• Semiconductor
Location
Ref. No.
Location
D1001 C-5
D3501 A-4
D3502 A-4
IC101 D-3
IC102 C-3
IC103 C-4
IC104 C-4
IC106 C-5
IC201 D-5
Q103 C-2
✩
IC103 (EEP ROM) can not be replaced individually.
Replace it with DMB10 board assembly for service.
• See page 27 for Circuit Boards Location. :Uses unleaded solder.
IC102
IC101
IC103
IC106
IC104
IC201
OPTICAL
PICK-UP
BLOCK
(KHM-310CAB)
I
I/O
BOARD
CN201
(Page 56)
