Sony HCD-FX10 - Printed Wiring Board - I;O Section (Side A)

5555
HCD-FX10
HCD-FX10
6-24. PRINTED WIRING BOARD – I/O SECTION (SIDE A) –
• See page 27 for Circuit Boards Location. :Uses unleaded solder.
• Semiconductor
Location
Ref. No. Location
IC201 B-6
IC203 B-5
IC204 B-5
IC601 B-4
IC602 B-3
IC608 B-3
Q603 B-4
Q604 B-4
IC602
IC601
IC204
IC203
IC201
IC608
E
E
12
A
B
C
D
34567
