88
HCD-FX10
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
IC602 8-759-649-89 IC MC4558CD
IC603 6-600-014-01 IC TORX141L (OPTICAL DIGITAL IN)
IC608 8-759-649-50 IC SN74AHC1GU04DCKR
< JACK >
J201 1-780-211-11 TERMINAL BOARD (S TERMINAL+1P)
(MONITOR OUT)
J202 1-817-449-11 JACK, PIN 3P (COMPONENT VIDEO OUT)
J601 1-816-605-11 JACK, PIN 6P (AUDIO IN/VIDEO IN)
J604 1-784-431-11 JACK, PIN 1P (COAXIAL IN)
< COIL >
L101 1-469-525-91 INDUCTOR 10uH
L201 1-469-525-91 INDUCTOR 10uH
L202 1-469-525-91 INDUCTOR 10uH
L601 1-469-525-91 INDUCTOR 10uH
L602 1-469-525-91 INDUCTOR 10uH
L604 1-469-525-91 INDUCTOR 10uH
< TRANSISTOR >
Q603 8-729-901-00 TRANSISTOR DTC124EK
Q604 8-729-901-00 TRANSISTOR DTC124EK
< RESISTOR >
R102 1-216-864-11 SHORT CHIP 0
R105 1-216-845-11 METAL CHIP 100K 5% 1/10W
R109 1-216-864-11 SHORT CHIP 0
R114 1-216-864-11 SHORT CHIP 0
R115 1-216-845-11 METAL CHIP 100K 5% 1/10W
R116 1-216-845-11 METAL CHIP 100K 5% 1/10W
R117 1-216-845-11 METAL CHIP 100K 5% 1/10W
R201 1-218-285-11 METAL CHIP 75 5% 1/10W
R202 1-218-285-11 METAL CHIP 75 5% 1/10W
R203 1-216-864-11 SHORT CHIP 0
R204 1-216-821-11 METAL CHIP 1K 5% 1/10W
R205 1-216-864-11 SHORT CHIP 0
R206 1-216-864-11 SHORT CHIP 0
R207 1-216-864-11 SHORT CHIP 0
R209 1-216-864-11 SHORT CHIP 0
R226 1-216-864-11 SHORT CHIP 0
R228 1-216-833-11 METAL CHIP 10K 5% 1/10W
R229 1-218-285-11 METAL CHIP 75 5% 1/10W
R230 1-218-285-11 METAL CHIP 75 5% 1/10W
R231 1-218-285-11 METAL CHIP 75 5% 1/10W
R232 1-218-285-11 METAL CHIP 75 5% 1/10W
R233 1-218-285-11 METAL CHIP 75 5% 1/10W
R241 1-218-285-11 METAL CHIP 75 5% 1/10W
R601 1-216-833-11 METAL CHIP 10K 5% 1/10W
R602 1-216-833-11 METAL CHIP 10K 5% 1/10W
R603 1-216-833-11 METAL CHIP 10K 5% 1/10W
R604 1-216-833-11 METAL CHIP 10K 5% 1/10W
R607 1-216-841-11 METAL CHIP 47K 5% 1/10W
R608 1-216-841-11 METAL CHIP 47K 5% 1/10W
R609 1-216-817-11 METAL CHIP 470 5% 1/10W
R610 1-216-817-11 METAL CHIP 470 5% 1/10W
R611 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R612 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R613 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R614 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R615 1-216-841-11 METAL CHIP 47K 5% 1/10W
R616 1-216-841-11 METAL CHIP 47K 5% 1/10W
R617 1-216-821-11 METAL CHIP 1K 5% 1/10W
R618 1-216-833-11 METAL CHIP 10K 5% 1/10W
R619 1-216-821-11 METAL CHIP 1K 5% 1/10W
R620 1-216-833-11 METAL CHIP 10K 5% 1/10W
R623 1-216-841-11 METAL CHIP 47K 5% 1/10W
R624 1-216-841-11 METAL CHIP 47K 5% 1/10W
R625 1-216-841-11 METAL CHIP 47K 5% 1/10W
R626 1-216-841-11 METAL CHIP 47K 5% 1/10W
R627 1-216-841-11 METAL CHIP 47K 5% 1/10W
R628 1-216-841-11 METAL CHIP 47K 5% 1/10W
R635 1-216-833-11 METAL CHIP 10K 5% 1/10W
R648 1-216-833-11 METAL CHIP 10K 5% 1/10W
R649 1-216-833-11 METAL CHIP 10K 5% 1/10W
R650 1-216-833-11 METAL CHIP 10K 5% 1/10W
R651 1-216-833-11 METAL CHIP 10K 5% 1/10W
R654 1-216-833-11 METAL CHIP 10K 5% 1/10W
R655 1-216-833-11 METAL CHIP 10K 5% 1/10W
R656 1-216-833-11 METAL CHIP 10K 5% 1/10W
R659 1-216-809-11 METAL CHIP 100 5% 1/10W
R661 1-216-809-11 METAL CHIP 100 5% 1/10W
R664 1-216-841-11 METAL CHIP 47K 5% 1/10W
R665 1-216-817-11 METAL CHIP 470 5% 1/10W
R666 1-218-285-11 METAL CHIP 75 5% 1/10W
R669 1-216-864-11 SHORT CHIP 0
R670 1-216-864-11 SHORT CHIP 0
************************************************************
KEY BOARD
*********
< RESISTOR >
R851 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R852 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R853 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R855 1-216-821-11 METAL CHIP 1K 5% 1/10W
R856 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R857 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R858 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
< SWITCH >
S801 1-786-763-11 SWITCH, TACTILE (.)
S802 1-786-763-11 SWITCH, TACTILE (VOLUME +)
S804 1-786-763-11 SWITCH, TACTILE (FUNCTION)
S805 1-786-763-11 SWITCH, TACTILE (X)
S806 1-786-763-11 SWITCH, TACTILE (x)
S807 1-786-763-11 SWITCH, TACTILE (>)
S808 1-786-763-11 SWITCH, TACTILE (VOLUME –)
************************************************************
LED BOARD
*********
< CONNECTOR >
CN803 1-784-867-21 CONNECTOR, FFC (LIF (NON-ZIF)) 15P
