HCD-FX10
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
101 A-1074-640-A TUNER UNIT (DTP-005 UC)
102 1-828-952-11 WIRE (FLAT TYPE) (9 CORE)
103 A-1104-737-A I/O BOARD, COMPLETE
104 1-787-331-11 FAN, D.C.
105 4-217-350-11 STOPPER, CORD
0 106 1-783-531-91 CORD, POWER
107 3-077-331-21 +BV3 (3-CR)
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
#4 7-685-881-09 SCREW +BVTT 4X8 (S)
7-3. CHASSIS SECTION-1
101
102
103 104
105
106
107
107
chassis section-2
#4
#2
#2
#2
#2
not supplied
not supplied
not supplied
not supplied
not supplied
