Sony HCD-FX10 - Page 61

61
HCD-FX10
IC201 MM1623BFBE
200 Ω
75Ω
DRIVER
75Ω
DRIVER
75Ω
DRIVER
75Ω
DRIVER
6.75MHz
LPF
6.75MHz
LPF
6.75MHz
LPF
13.5MHz
LPF
6.75MHz
6dB
6dB
6dB
6dB-6dB
6dB
LPF
75Ω
DRIVER
13.5MHz
LPF
6.75MHz
6dB
LPF
75Ω
DRIVER
13.5MHz
LPF
6.75MHz
6dB
LPF
BIAS
CLAMP
CLAMP
CLAMP
150kΩ
BIAS
S-DC OUT
S1/S2
VCC1
C IN
MUTE 1
CVBS IN
YC MIX
Y IN
GND1
BIAS
I/P
CY IN
CLP
CB IN
MUTE2
CR IN
VCC2
S-DC OUT
C OUT
S1
S2
CVBS OUT
GND2
CY OUT
Y OUT
GND2
CB OUT
GND2
CR OUT
GND2
28
2
1
27
3
26
4 25
5
24
6
23
7
22
8 21
9
20
10
19
11
18
12 17
13 16
14 15
150kΩ
BIAS
150kΩ
BIAS
150kΩ
BIAS
IC601 MC14052BDR2
– I/O Board –
IC203 NJM2235V (TE2)
1
2
3
4
6
5
7
8
IN 1
SW 1
SW 2
VDD
VIN 3
OUT
GND
IN 2
BIAS
BUFFER
