86
HCD-FX10
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-1104-753-A FL BOARD, COMPLETE
******************
< CAPACITOR >
C800 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C801 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C802 1-126-795-11 ELECT 10uF 20% 50V
C803 1-124-584-00 ELECT 100uF 20% 10V
C804 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C805 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C806 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C808 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C809 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C810 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C811 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C812 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C813 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C814 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C815 1-117-370-11 CERAMIC CHIP 10uF 10V
C816 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C817 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C818 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C819 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C820 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C821 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C822 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C823 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C824 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C825 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C826 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C827 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C828 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C829 1-126-795-11 ELECT 10uF 20% 50V
C833 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C881 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C882 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C883 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C884 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C885 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C886 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C887 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C888 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C889 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C890 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C891 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
< CONNECTOR >
CN801 1-794-354-11 CONNECTOR, FFC/FPC 19P
CN802 1-784-867-21 CONNECTOR, FFC (LIF (NON-ZIF)) 15P
CN804 1-506-468-11 PIN, CONNECTOR 3P
< DIODE >
D801 8-719-988-61 DIODE 1SS355TE-17
D802 8-719-988-61 DIODE 1SS355TE-17
D803 8-719-069-56 DIODE UDZSTE-176.2B
D804 8-719-988-61 DIODE 1SS355TE-17
D805 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB801 1-414-813-11 FERRITE, EMI (SMD) (2012)
FB802 1-414-813-11 FERRITE, EMI (SMD) (2012)
< FLUORESCENT INDICATOR >
FL801 1-519-810-11 VACUUM FLUORESCENT DISPLAYS
< IC >
IC801 6-600-349-21 IC NJL23H400A ( )
IC802 6-704-046-01 IC BU2099FV
IC803 6-705-899-01 IC ML9208-03MBZ03B
< COIL >
L801 1-410-671-31 INDUCTOR 47uH
L802 1-400-135-11 INDUCTOR 1uH
L803 1-400-135-11 INDUCTOR 1uH
L804 1-400-135-11 INDUCTOR 1uH
< TRANSISTOR >
Q801 6-550-065-01 TRANSISTOR CPH5504-TL-E
Q802 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R801 1-216-839-11 METAL CHIP 33K 5% 1/10W
R802 1-216-809-11 METAL CHIP 100 5% 1/10W
R804 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R805 1-216-295-91 SHORT CHIP 0
R810 1-216-864-11 SHORT CHIP 0
R812 1-216-864-11 SHORT CHIP 0
R813 1-216-809-11 METAL CHIP 100 5% 1/10W
R814 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R815 1-216-809-11 METAL CHIP 100 5% 1/10W
R816 1-216-809-11 METAL CHIP 100 5% 1/10W
R817 1-216-809-11 METAL CHIP 100 5% 1/10W
R818 1-216-809-11 METAL CHIP 100 5% 1/10W
R819 1-216-809-11 METAL CHIP 100 5% 1/10W
R820 1-216-833-11 METAL CHIP 10K 5% 1/10W
R821 1-216-805-11 METAL CHIP 47 5% 1/10W
R845 1-216-821-11 METAL CHIP 1K 5% 1/10W
R846 1-216-809-11 METAL CHIP 100 5% 1/10W
R872 1-216-821-11 METAL CHIP 1K 5% 1/10W
R875 1-216-845-11 METAL CHIP 100K 5% 1/10W
< TRANSFORMER >
T801 1-443-757-11 TRANSFORMER, DC-DC CONVERTER
************************************************************
H/P BOARD
*********
< CAPACITOR >
C862 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C866 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C870 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C872 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C873 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
H/PFL
