11
HCD-GN77D
3-7. CD SWITCH BOARD, DISPLAY BOARD
3-8. VOLUME BOARD
1
Six screws
(+BVTP2.6 x 8)
4
Five screws
(+BVTP2.6 x 8)
3
Wire (flat type) (17 core)
from CN604
5
DISPLAY board
4
Five screws
(+BVTP2.6 x 8)
2
CD SWITCH board
1
Knob (VOL)
5
VOLUME board
3
Three screws
(+BVTP2.6 x 8)
3
Three screws
(+BVTP2.6 x 8
)
4
Four claws
2
Hexagonal nut
