8
HCD-GN77D
Note: Follow the disassembly procedure in the numerical order given.
3-1. CASE
3-2. LOADING (PANEL)
1
Three screws
(case 3 TP2)
2
Five screws
(+BVTT3 x 6)
7
Case
6
4
1
Three screws
(case 3 TP2)
3
Tw o screws
(+BVTT3 x 6
5
Slightly push down
the edge of front panel
not to break the catcher.
Catcher
CD mechanismdeck (CDM74-K6BD47S)
1
Tu rn the pulley to the arrow direction.
Front side
Pulley
4
Loading (panel)
3
2
Pull out disc tray
