Sony HCD-GN77D - Circuit Board Locations; Component Board Locations

24
HCD-GN77D
7-1. CIRCUIT BOARD LOCATION
TUNER PACK
SUB TRANS board
SURROUND board
POWER AMP board
TRANS board
DISPLAY board
VOLUME board
GAME IN board
MOTOR (LD) board
SW board
SENSOR board
RF board
MOTOR (TB) board
DRIVER board
MAIN board
CD SWITCH board
DMB03 board
REGULATOR
board
VIDEO board
