84
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-GN77D
SECTION 9
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
•Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µ PD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
CD SWITCH DISPLAY
• Abbreviation
E3 : 240 V AC Area in E model
EA : Saudi Arabia model
E15 : Iran model
SP : Singapore model
MY : Malaysia model
TH : Thai model
1-686-936-11 CD SWITCH BOARD
***************
< DIODE >
D748 8-719-058-04 DIODE SEL5223S-TP15 (=/1)
< TRANSISTOR >
Q748 8-729-116-02 TRANSISTOR BA1A4M-TP
< RESISTOR >
R748 1-249-411-11 CARBON 330 5% 1/4W
R749 1-249-410-11 CARBON 270 5% 1/4W F
R788 1-249-427-11 CARBON 6.8K 5% 1/4W F
R789 1-249-429-11 CARBON 10K 5% 1/4W
R790 1-249-431-11 CARBON 15K 5% 1/4W
R791 1-249-433-11 CARBON 22K 5% 1/4W
R792 1-249-435-11 CARBON 33K 5% 1/4W
< SWITCH >
S749 1-762-875-21 SWITCH, KEYBOARD (=/1)
S788 1-762-875-21 SWITCH, KEYBOARD (ZOPEN/CLOSE)
S789 1-762-875-21 SWITCH, KEYBOARD (EX-CHANGE/DISK SKIP)
S790 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
S791 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
S792 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
******************************************************
A-4732-870-A DISPLAY BOARD, COMPLETE (EXCEPT TH)
A-4734-535-A DISPLAY BOARD, COMPLETE (TH)
*********************
4-231-581-01 HOLDER (FL)
< CAPACITOR >
C100 1-126-964-11 ELECT 10uF 20% 50V
C101 1-137-194-81 FILM 0.47uF 5% 50V
C102 1-137-194-81 FILM 0.47uF 5% 50V
C104 1-126-964-11 ELECT 10uF 20% 50V
C105 1-126-957-11 ELECT 0.22uF 20% 50V
C106 1-136-165-00 FILM 0.1uF 5% 50V
C107 1-136-165-00 FILM 0.1uF 5% 50V
C109 1-124-261-00 ELECT 10uF 20% 50V
C110 1-126-957-11 ELECT 0.22uF 20% 50V
C111 1-136-157-00 FILM 0.022uF 5% 50V
C112 1-136-157-00 FILM 0.022uF 5% 50V
C114 1-126-964-11 ELECT 10uF 20% 50V
C115 1-126-957-11 ELECT 0.22uF 20% 50V
C116 1-130-475-00 MYLAR 0.0022uF 5% 50V
C117 1-130-475-00 MYLAR 0.0022uF 5% 50V
C118 1-126-964-11 ELECT 10uF 20% 50V
C119 1-124-261-00 ELECT 10uF 20% 50V
C120 1-126-957-11 ELECT 0.22uF 20% 50V
C121 1-126-963-11 ELECT 4.7uF 20% 50V
C122 1-124-584-00 ELECT 100uF 20% 10V
C123 1-104-665-11 ELECT 100uF 20% 10V
C124 1-126-964-11 ELECT 10uF 20% 50V
C125 1-164-159-21 CERAMIC 0.1uF 50V(TH)
C125 1-164-159-11 CERAMIC 0.1uF 50V
(EXCEPT TH)
C152 1-162-286-21 CERAMIC 220PF 10% 50V(TH)
C152 1-162-286-31 CERAMIC 220PF 10% 50V
(EXCEPT TH)
C153 1-162-286-21 CERAMIC 220PF 10% 50V(TH)
C153 1-162-286-31 CERAMIC 220PF 10% 50V
(EXCEPT TH)
C154 1-162-286-21 CERAMIC 220PF 10% 50V(TH)
C154 1-162-286-31 CERAMIC 220PF 10% 50V
(EXCEPT TH)
C155 1-162-286-21 CERAMIC 220PF 10% 50V(TH)
C155 1-162-286-31 CERAMIC 220PF 10% 50V
(EXCEPT TH)
C156 1-162-286-21 CERAMIC 220PF 10% 50V(TH)
C156 1-162-286-31 CERAMIC 220PF 10% 50V
(EXCEPT TH)
C157 1-162-286-21 CERAMIC 220PF 10% 50V(TH)
C157 1-162-286-31 CERAMIC 220PF 10% 50V
(EXCEPT TH)
C618 1-162-306-11 CERAMIC 0.01uF 30% 16V
C619 1-124-589-11 ELECT 47uF 20% 16V
C620 1-162-306-11 CERAMIC 0.01uF 30% 16V
C622 1-126-163-11 ELECT 4.7uF 20% 50V
C623 1-162-294-31 CERAMIC 0.001uF 10% 50V
C624 1-162-306-11 CERAMIC 0.01uF 30% 16V
C625 1-162-306-11 CERAMIC 0.01uF 30% 16V
C626 1-162-306-11 CERAMIC 0.01uF 30% 16V
C627 1-162-306-11 CERAMIC 0.01uF 30% 16V
C628 1-162-306-11 CERAMIC 0.01uF 30% 16V
C651 1-164-159-21 CERAMIC 0.1uF 50V(TH)
C651 1-164-159-11 CERAMIC 0.1uF 50V
(EXCEPT TH)
C652 1-124-261-00 ELECT 10uF 20% 50V
C653 1-124-261-00 ELECT 10uF 20% 50V
C710 1-162-306-11 CERAMIC 0.01uF 30% 16V
