Sony HCD-GN77D - Electrical Parts List: Main Board Resistors (Cont.); Main Board Resistors (Continued)

97
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-GN77D
MAIN
R448 1-216-809-11 METAL CHIP 100 5% 1/10W
R450 1-216-809-11 METAL CHIP 100 5% 1/10W
R473 1-216-809-11 METAL CHIP 100 5% 1/10W
R474 1-216-809-11 METAL CHIP 100 5% 1/10W
R477 1-216-833-11 METAL CHIP 10K 5% 1/10W
R478 1-216-833-11 METAL CHIP 10K 5% 1/10W
R488 1-216-809-11 METAL CHIP 100 5% 1/10W
R492 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R493 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(E3,E15,EA)
R493 1-216-864-11 METAL CHIP 0 5% 1/10W
(SP,MY,TH)
R495 1-216-839-11 METAL CHIP 33K 5% 1/10W
R501 1-216-809-11 METAL CHIP 100 5% 1/10W
R502 1-216-809-11 METAL CHIP 100 5% 1/10W
R503 1-216-809-11 METAL CHIP 100 5% 1/10W
R504 1-216-809-11 METAL CHIP 100 5% 1/10W
R505 1-216-809-11 METAL CHIP 100 5% 1/10W
R506 1-216-809-11 METAL CHIP 100 5% 1/10W
R507 1-216-809-11 METAL CHIP 100 5% 1/10W
R509 1-216-833-11 METAL CHIP 10K 5% 1/10W
R511 1-216-851-11 METAL CHIP 330K 5% 1/10W
R513 1-216-864-11 METAL CHIP 0 5% 1/10W
R517 1-216-833-11 METAL CHIP 10K 5% 1/10W
R519 1-216-833-11 METAL CHIP 10K 5% 1/10W
R521 1-216-809-11 METAL CHIP 100 5% 1/10W
R522 1-216-809-11 METAL CHIP 100 5% 1/10W
R523 1-216-833-11 METAL CHIP 10K 5% 1/10W
R529 1-216-833-11 METAL CHIP 10K 5% 1/10W
R530 1-216-833-11 METAL CHIP 10K 5% 1/10W
R540 1-216-809-11 METAL CHIP 100 5% 1/10W
R541 1-216-809-11 METAL CHIP 100 5% 1/10W
R542 1-216-833-11 METAL CHIP 10K 5% 1/10W
R543 1-216-833-11 METAL CHIP 10K 5% 1/10W
R544 1-216-833-11 METAL CHIP 10K 5% 1/10W
R545 1-216-833-11 METAL CHIP 10K 5% 1/10W
R549 1-216-833-11 METAL CHIP 10K 5% 1/10W
R550 1-216-833-11 METAL CHIP 10K 5% 1/10W
R560 1-216-809-11 METAL CHIP 100 5% 1/10W
R561 1-216-809-11 METAL CHIP 100 5% 1/10W
R563 1-216-833-11 METAL CHIP 10K 5% 1/10W
R566 1-216-809-11 METAL CHIP 100 5% 1/10W
R567 1-216-809-11 METAL CHIP 100 5% 1/10W
R569 1-216-809-11 METAL CHIP 100 5% 1/10W
R572 1-216-809-11 METAL CHIP 100 5% 1/10W
R573 1-216-833-11 METAL CHIP 10K 5% 1/10W
R574 1-216-833-11 METAL CHIP 10K 5% 1/10W
R575 1-216-809-11 METAL CHIP 100 5% 1/10W
R576 1-216-813-11 METAL CHIP 220 5% 1/10W
R577 1-216-809-11 METAL CHIP 100 5% 1/10W
R578 1-216-809-11 METAL CHIP 100 5% 1/10W
R579 1-216-809-11 METAL CHIP 100 5% 1/10W
R580 1-216-809-11 METAL CHIP 100 5% 1/10W
R581 1-216-809-11 METAL CHIP 100 5% 1/10W
R582 1-216-809-11 METAL CHIP 100 5% 1/10W
R583 1-216-809-11 METAL CHIP 100 5% 1/10W
R584 1-216-809-11 METAL CHIP 100 5% 1/10W
R585 1-216-809-11 METAL CHIP 100 5% 1/10W
R586 1-216-809-11 METAL CHIP 100 5% 1/10W
R587 1-216-809-11 METAL CHIP 100 5% 1/10W
R588 1-216-809-11 METAL CHIP 100 5% 1/10W
R589 1-216-809-11 METAL CHIP 100 5% 1/10W
R590 1-216-809-11 METAL CHIP 100 5% 1/10W
R591 1-216-809-11 METAL CHIP 100 5% 1/10W
R592 1-216-819-11 METAL CHIP 680 5% 1/10W
R593 1-216-821-11 METAL CHIP 1K 5% 1/10W
(E3,E15,EA)
R593 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(SP,MY)
R594 1-216-809-11 METAL CHIP 100 5% 1/10W
R595 1-216-821-11 METAL CHIP 1K 5% 1/10W
R597 1-216-864-11 METAL CHIP 0 5% 1/10W
R598 1-216-809-11 METAL CHIP 100 5% 1/10W
R600 1-216-809-11 METAL CHIP 100 5% 1/10W
R601 1-216-813-11 METAL CHIP 220 5% 1/10W
R602 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R603 1-216-841-11 METAL CHIP 47K 5% 1/10W
R604 1-216-841-11 METAL CHIP 47K 5% 1/10W
R620 1-216-833-11 METAL CHIP 10K 5% 1/10W
R621 1-216-821-11 METAL CHIP 1K 5% 1/10W
R622 1-216-841-11 METAL CHIP 47K 5% 1/10W
R623 1-216-833-11 METAL CHIP 10K 5% 1/10W
R624 1-215-891-11 METAL OXIDE 680 5% 2W
R625 1-216-821-11 METAL CHIP 1K 5% 1/10W
R626 1-216-806-11 METAL CHIP 56 5% 1/10W
R629 1-216-817-11 METAL CHIP 470 5% 1/10W
R630 1-216-817-11 METAL CHIP 470 5% 1/10W
R650 1-216-835-11 METAL CHIP 15K 5% 1/10W
R651 1-216-853-11 METAL CHIP 470K 5% 1/10W
R652 1-216-843-11 METAL CHIP 68K 5% 1/10W
R653 1-216-821-11 METAL CHIP 1K 5% 1/10W
R654 1-216-845-11 METAL CHIP 100K 5% 1/10W
R655 1-216-845-11 METAL CHIP 100K 5% 1/10W
R656 1-216-833-11 METAL CHIP 10K 5% 1/10W
R670 1-216-833-11 METAL CHIP 10K 5% 1/10W
R671 1-216-821-11 METAL CHIP 1K 5% 1/10W
R672 1-216-841-11 METAL CHIP 47K 5% 1/10W
R673 1-216-833-11 METAL CHIP 10K 5% 1/10W
R674 1-215-891-11 METAL OXIDE 680 5% 2W
R675 1-216-821-11 METAL CHIP 1K 5% 1/10W
R676 1-216-806-11 METAL CHIP 56 5% 1/10W
0R701 1-249-409-11 CARBON 220 5% 1/4W F
R702 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R720 1-216-821-11 METAL CHIP 1K 5% 1/10W
R721 1-216-845-11 METAL CHIP 100K 5% 1/10W
R722 1-216-821-11 METAL CHIP 1K 5% 1/10W
R730 1-216-833-11 METAL CHIP 10K 5% 1/10W
R770 1-216-821-11 METAL CHIP 1K 5% 1/10W
R771 1-216-845-11 METAL CHIP 100K 5% 1/10W
R772 1-216-821-11 METAL CHIP 1K 5% 1/10W
R798 1-216-809-11 METAL CHIP 100 5% 1/10W
R799 1-216-809-11 METAL CHIP 100 5% 1/10W
R800 1-216-841-11 METAL CHIP 47K 5% 1/10W
R801 1-216-817-11 METAL CHIP 470 5% 1/10W
R802 1-216-833-11 METAL CHIP 10K 5% 1/10W
R803 1-216-841-11 METAL CHIP 47K 5% 1/10W
R804 1-216-841-11 METAL CHIP 47K 5% 1/10W
The components identified by mark 0 or dotted line
with mark 0 are critical for safety.
Replace only with part number specified.
