Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
79
HCD-VX888
R733 1-249-431-11 CARBON 15K 5% 1/4W
R734 1-247-807-31 CARBON 100 5% 1/4W
R735 1-247-885-00 CARBON 180K 5% 1/4W
R736 1-249-429-11 CARBON 10K 5% 1/4W
R737 1-249-437-11 CARBON 47K 5% 1/4W
R738 1-249-417-11 CARBON 1K 5% 1/4W
R739 1-249-441-11 CARBON 100K 5% 1/4W
R740 1-249-417-11 CARBON 1K 5% 1/4W
R741 1-249-429-11 CARBON 10K 5% 1/4W
R742 1-249-417-11 CARBON 1K 5% 1/4W
R743 1-249-429-11 CARBON 10K 5% 1/4W
R744 1-249-441-11 CARBON 100K 5% 1/4W
R745 1-247-807-31 CARBON 100 5% 1/4W
R746 1-249-417-11 CARBON 1K 5% 1/4W
R747 1-260-089-11 CARBON 150 5% 1/2W
R748 1-249-441-11 CARBON 100K 5% 1/4W
R811 1-249-417-11 CARBON 1K 5% 1/4W
R812 1-249-417-11 CARBON 1K 5% 1/4W
< VARIABLE RESISTOR >
RV721 1-227-360-11 RES, VAR, CARBON 50K (ECHO LEVEL)
RV722 1-227-360-11 RES, VAR, CARBON 50K (MIC LEVEL)
< SWITCH >
S601 1-771-410-21 SWITCH, TACTILE (MD (VIDEO))
S602 1-771-410-21 SWITCH, TACTILE (TAPE A/B)
S603 1-771-410-21 SWITCH, TACTILE (CD)
S604 1-771-410-21 SWITCH, TACTILE (TUNER/BAND)
S605 1-771-410-21 SWITCH, TACTILE (GAME)
S606 1-771-410-21 SWITCH, TACTILE
(SURROUND SPEAKER MODE)
< VIBRATOR >
X601 1-577-358-21 VIBRATOR, CERAMIC (4MHz)
**************************************************************
A-4475-766-A POWER AMPLIFIER BOARD, COMPLETE
(EA, E3, SP2/6)
A-4476-338-A POWER AMPLIFIRE BOARD, COMPLETE (IA)
A-4725-790-A POWER AMPLIFIER BOARD, COMPLETE (E91)
********************************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C501 1-126-963-11 ELECT 4.7uF 20% 50V
C502 1-162-286-21 CERAMIC 220PF 10% 50V
C503 1-162-282-31 CERAMIC 100PF 10% 50V
C504 1-104-665-11 ELECT 100uF 20% 10V
C507 1-136-495-11 FILM 0.068uF 5% 50V
C508 1-136-495-11 FILM 0.068uF 5% 50V
C509 1-128-560-11 ELECT 22uF 20% 100V
C512 1-162-300-11 CERAMIC 0.01 30% 16V
C513 1-164-159-11 CERAMIC 0.1uF 50V
C514 1-164-159-11 CERAMIC 0.1uF 50V
C541 1-136-165-00 FILM 0.1uF 5% 50V
C542 1-137-844-11 ELECT 2200uF 20% 42V
C544 1-137-749-11 MYLAR 0.1uF 100V
C545 1-137-749-11 MYLAR 0.1uF 100V
C546 1-137-849-11 ELECT 2200uF 20% 100V
C551 1-126-963-11 ELECT 4.7uF 20% 50V
C552 1-162-286-21 CERAMIC 220PF 10% 50V
C553 1-162-282-31 CERAMIC 100PF 10% 50V
C554 1-104-665-11 ELECT 100uF 20% 10V
C557 1-136-495-11 FILM 0.068uF 5% 50V
C558 1-136-495-11 FILM 0.068uF 5% 50V
C559 1-128-560-11 ELECT 22uF 20% 100V
C581 1-126-967-11 ELECT 47uF 20% 50V
C591 1-136-165-00 FILM 0.1uF 5% 50V
C592 1-137-844-11 ELECT 2200uF 20% 42V
C596 1-137-849-11 ELECT 2200uF 20% 100V
C942 1-126-964-11 ELECT 10uF 20% 50V
C943 1-126-968-11 ELECT 100uF 20% 50V
< CONNECTOR >
CN502 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
CN503 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
CN504 1-506-468-11 PIN, CONNECTOR 3P
< DIODE >
D501 8-719-911-19 DIODE 1SS133T-72
D502 8-719-911-19 DIODE 1SS133T-72
D503 8-719-947-70 DIODE MTZJ-T-72-18C
D504 8-719-947-70 DIODE MTZJ-T-72-18C
D541 8-719-500-60 DIODE D5SBA20
D543 8-719-510-68 DIODE D5SBA204101
D551 8-719-911-19 DIODE 1SS133T-72
D581 8-719-911-19 DIODE 1SS133T-72
D941 8-719-150-92 DIODE MTZJ-T-72-33D
< EARTH TERMINAL >
* EP501 1-537-738-21 TERMINAL, EARTH
* EP502 1-537-738-21 TERMINAL, EARTH
< IC >
IC501 8-749-017-06 IC STK412-150
< TRANSISTOR >
Q501 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q503 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q504 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q505 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q506 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q551 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q581 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q831 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q941 8-729-141-83 TRANSISTOR 2SB1375
< RESISTOR >
R501 1-249-417-11 CARBON 1K 5% 1/4W
R502 1-249-438-11 CARBON 56K 5% 1/4W
R503 1-249-412-11 CARBON 390 5% 1/4W
R504 1-249-438-11 CARBON 56K 5% 1/4W
R505 1-249-417-11 CARBON 1K 5% 1/4W
PANEL POWER AMPLIFIER
