Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
80
HCD-VX888
POWER AMPLIFIER SENSOR SUB TRANS VIDEO
R506 1-249-433-11 CARBON 22K 5% 1/4W
R507 1-249-441-11 CARBON 100K 5% 1/4W
0R508 1-208-603-11 WIREWOUND 0.1 10% 5W F
R509 1-260-076-11 CARBON 10 5% 1/2W
0R510 1-208-603-11 WIREWOUND 0.1 10% 5W F
0R511 1-212-881-11 FUSIBLE 100 5% 1/4W F
0R512 1-202-972-61 FUSIBLE 1 5% 1/4W F
R513 1-249-435-11 CARBON 33K 5% 1/4W
R514 1-249-421-11 CARBON 2.2K 5% 1/4W
R515 1-249-433-11 CARBON 22K 5% 1/4W
R516 1-249-429-11 CARBON 10K 5% 1/4W
R517 1-249-421-11 CARBON 2.2K 5% 1/4W
R518 1-249-435-11 CARBON 33K 5% 1/4W
R519 1-249-439-11 CARBON 68K 5% 1/4W
0R520 1-215-872-11 METAL OXIDE 3.3K 5% 1W F
R521 1-249-441-11 CARBON 100K 5% 1/4W
R522 1-249-441-11 CARBON 100K 5% 1/4W
R523 1-249-440-11 CARBON 82K 5% 1/4W
0R524 1-215-872-11 METAL OXIDE 3.3K 5% 1W F
R531 1-249-409-11 CARBON 220 5% 1/4W
R532 1-247-897-11 CARBON 560K 5% 1/4W
R533 1-249-437-11 CARBON 47K 5% 1/4W
R541 1-249-441-11 CARBON 100K 5% 1/4W
R542 1-249-441-11 CARBON 100K 5% 1/4W
R551 1-249-417-11 CARBON 1K 5% 1/4W
R552 1-249-438-11 CARBON 56K 5% 1/4W
R553 1-249-412-11 CARBON 390 5% 1/4W
R554 1-249-438-11 CARBON 56K 5% 1/4W
R555 1-249-417-11 CARBON 1K 5% 1/4W
R556 1-249-433-11 CARBON 22K 5% 1/4W
R557 1-249-441-11 CARBON 100K 5% 1/4W
0R558 1-208-603-11 WIREWOUND 0.1 10% 5W F
R559 1-260-076-11 CARBON 10 5% 1/2W
0R560 1-208-603-11 WIREWOUND 0.1 10% 5W F
0R561 1-212-881-11 FUSIBLE 100 5% 1/4W
R581 1-249-435-11 CARBON 33K 5% 1/4W
R582 1-249-435-11 CARBON 33K 5% 1/4W
R591 1-249-441-11 CARBON 100K 5% 1/4W
R592 1-249-441-11 CARBON 100K 5% 1/4W
R942 1-249-429-11 CARBON 10K 5% 1/4W
(EXCEPT E91)
R942 1-249-428-11 CARBON 8.2K 5% 1/4W
(E91)
R943 1-249-417-11 CARBON 1K 5% 1/4W
R945 1-249-428-11 CARBON 8.2K 5% 1/4W
(E91)
R945 1-249-429-11 CARBON 10K 5% 1/4W
(EXCEPT E91)
**************************************************************
1-681-143-11 SENSOR BOARD
*************
< CONNECTOR >
CN701 1-568-951-11 PIN, CONNECTOR 2P
< THERMISTOR >
TH701 1-807-796-11 THERMISTOR
**************************************************************
A-4476-114-A SUB TRANS BOARD, COMPLETE
(E3, EA, SP2/6)
A-4476-773-A SUB TRANS BOARD, COMPLETE (IA)
A-4725-793-A SUB TRANS BOARD, COMPLETE (E91)
**************************
< CAPACITOR >
0C971 1-113-925-11 CERAMIC 0.01uF 20% 250V
0C972 1-113-925-11 CERAMIC 0.01uF 20% 250V
C973 1-126-933-11 ELECT 100uF 20% 16V
C975 1-126-768-11 ELECT 2200uF 20% 16V
C976 1-164-159-11 CERAMIC 0.1uF 50V
C977 1-164-159-11 CERAMIC 0.1uF 50V
C978 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN972 1-564-321-21 PIN, CONNECTOR 2P
* CN974 1-568-226-11 PIN, CONNECTOR 2P
< DIODE >
D971 8-719-911-19 DIODE 1SS133T-72
D972 8-719-024-99 DIODE 11ES2-NTA2B
D973 8-719-024-99 DIODE 11ES2-NTA2B
D974 8-719-024-99 DIODE 11ES2-NTA2B
D975 8-719-024-99 DIODE 11ES2-NTA2B
< IC >
IC971 8-759-158-62 IC TA78057S
< TRANSISTOR >
Q971 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
< RESISTOR >
R974 1-249-441-11 CARBON 100K 5% 1/4W
R975 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
0RY971 1-755-276-11 RELAY, POWER
0RY972 1-755-276-11 RELAY, POWER
< SWITCH >
0S901 1-786-055-21 SELECTOR, VOLTAGE (VOLTAGE SELECTOR)
(EXCEPT E91)
< TRANSFORMER >
0T972 1-437-331-21 TRANSFORMER, POWER
**************************************************************
A-4725-689-A VIDEO BOARD, COMPLETE (E3, EA, SP2/6)
A-4725-691-A VIDEO BOARD, COMPLETE (IA)
A-4725-771-A VIDEO BOARD, COMPLETE (E91)
**********************
< CAPACITOR >
C101 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C102 1-164-670-11 CERAMIC CHIP 1200PF 5% 16V
C103 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
