Sony ICP-X1224

155
Speed
Rotates a pattern at a fixed speed.
Magnitude
Rotates a pattern through the specified angle in a single
tra
nsition.
1 Open the Home > M/E-1 > Bus/Transition > Wipe >
Main Modify menu (11109.35).
2 In the [Rotation] group, select a rotation type.
When the [Angle] button is selected, set the following
p
arameter.
When the [Speed] button is selected, set the following
p
arameter.
When the [Magnitude] button is selected, set the
f
ollowing parameters.
Setting the aspect ratio of a wipe pattern
(Aspect)
You can change the aspect ratio of a pattern.
1 Open the Home > M/E-1 > Bus/Transition > Wipe >
Main Modify menu (11109.35).
2 Set the [Aspect] button to the on state and set the
following parameter.
Replicating a wipe pattern (Multi)
You can replicate a pattern horizontally, vertically, or
both up to 63 times.
You can also change the orientation of alternate patterns
or
change the position.
No. Parameter Adjustment
1 Angle Inclination angle of pattern
• A value of –100.00
co
rresponds to a rotation of
one turn counterclockwise.
• A value of +100.00
co
rresponds to a rotation of
one turn clockwise.
• A value of 0.00
co
rresponds to no rotation.
No. Parameter Adjustment
1 Speed Rotation speed of pattern
• A value of –100.00
co
rresponds to 1 revolution/
second counterclockwise
rotation.
• A value of +100.00
co
rresponds to 1 revolution/
second clockwise rotation.
• A value of 0.00
co
rresponds to no rotation
(stationary).
No. Parameter Adjustment
1 Angle Angle of pattern at start of
tra
nsition
• A value of –100.00
c
orresponds to a rotation of
one turn counterclockwise.
• A value of +100.00
c
orresponds to a rotation of
one turn clockwise.
• A value of 0.00
c
orresponds to no rotation.
2 Magnitude Angle of rotation through
c
ourse of transition
• A value of –200.00
c
orresponds to a rotation of
two turns counterclockwise.
• A value of +200.00
c
orresponds to a rotation of
two turns clockwise.
• A value of 0.00
c
orresponds to no rotation.
No. Parameter Adjustment
1 Aspect Aspect ratio
• Negative values expand
v
ertically.
• Positive values expand
horizontally.
Aspect disabled Aspect enabled
