Router/Tally Setup
Copying router/tally settings information
When using two control panels in a switcher system, the
t
ally is controlled by control panel 1.
Consequently, the router/tally settings information for
con
trol panel 1 must be copied to control panel 2.
Copy the router/tally setup data using the Home > File
men
u, for example.
Different serial tally settings can be configured on control
pan
el 1 and control panel 2. After loading the setup data,
change the settings.
For details about Home > File menu operations, see
“Chapter 19 File Management” (page 329).
Setting the NS-Bus
Matrix
You can configure the required setting using the routing
function of LSM (Live System Manager). The LSM
interface uses the NS-Bus protocol.
Assigning Switcher Inputs/Outputs
The switcher matrix size is set to 320×348.
1
Open the Home > Setup > Router/Tally > NS-Bus >
Matrix menu (19106.11).
The settings status of the switcher and external boxes
is d
isplayed.
2
Select [Switcher] for [Device].
3
Press the [Source] button and enter an address for the
first source in the numeric keypad window.
4
Press the [Destination] button and enter an address
for the first destination in the numeric keypad
window.
5
Press the [Level] button and enter a level (1 to 8) in
the numeric keypad window.
Setting an External Box
You can configure a matrix for external boxes 1 to 12.
1
Open the Home > Setup > Router/Tally > NS-Bus >
Matrix menu (19106.11).
The settings status of the switcher and external boxes
is d
isplayed.
