b DME channel buttons
Selects DME channels (DME1 to DME4) to assign to a
key
.
The DME channel buttons assigned to the selected key
ar
e lit green. The DME channel buttons assigned to other
keys/buses are lit amber.
While the [TRANS] button/[SUB TRANS] button is
sel
ected, you can assign a DME channel to use in a DME
wipe.
c O
n-air indicators
When a DME channel is used as an on-air image, the
cor
responding indicator is lit red.
d Setti
ng buttons
Configures key settings.
Setting buttons for different functions are assigned to
t
hree pages (1/3, 2/3, 3/3), where you can switch the page
by pressing the page selection button.
You can check which functions are configured for the
bu
ttons in the setting button display area.
Key type selection buttons
Selects the key type.
When a button is selected, the parameters appear on the
di
splay and you can set the parameters using the
adjustment knobs.
• LUM: Luminance key
• LIN: Linear key
•CRK: Chroma key
• PTN: Key wipe pattern key
Key fill/key source selection buttons
Selects a key fill and key source.
When the [MAT FILL] button is selected, the parameters
appea
r on the display and you can set the parameters
using the adjustment knobs.
• AUTO SEL: Auto select mode
• SPLT: Split mode
• MAT FILL: Key fill color matte
When the [AUTO SEL] button and [SPLT] button are
bot
h selected, self mode is activated.
Key modifier setting buttons
Sets the key edges.
When a button is selected, the parameters appear on the
di
splay and you can set the parameters using the
adjustment knobs.
•BDR: Border
• DROP BDR: Drop border
• SHDW: Shadow
• SOFT EDGE: Soft edge
Resizer operation buttons
Performs two-dimensional transforms (shrink/magnify,
move,
rotate) on keys using a resizer.
When a button is selected, the parameters appear on the
di
splay and you can set the parameters using the
adjustment knobs.
• RSZR: Two-dimensional transform
• ROT X: Rotation around X-axis
• ROT Y: Rotation around Y-axis
Chroma key setting buttons
Sets a chroma key.
When the [SMPL MARK] button, [KEY ACTV] button,
or [CO
L CAN] button is selected, the parameters appear
on the display and you can set the parameters using the
adjustment knobs.
• SMPL MARK: Simple mark
• AUTO STRT: Executes an auto chroma key
• KEY ACTV: Key active
• COL CAN: Color cancel
Page selection button
Switches the page of setting buttons.
Each time the button is pressed, the page switches in the
or
der 1/3 t 2/3 t 3/3. The number of the currently
selected page is displayed in the setting button display
area.
SUB
TRANS
Used as the [TRANS] button on the sub side
when in multi program 2 mode.
Button
name
Description
Setting button display area: PAGE 2/3
Setting button display area: PAGE 3/3
Page selection button
Setting button display area: PAGE 1/3
Note
