Output numbers (Output)
1M/E box configuration
1M/E box + cross-point box configuration
No. System signal format
2160P Other than 2160P
Logical box ID Slot number Port number Logical box ID Slot number Port number
1 to 4 1 1 1 to 4 1 1 1 to 4
5 to 8 1 1 5 to 8 1 1 5 to 8
9 to 12 1 1 9 to 12 1 1 9 to 12
13 to 16 1 1 13 to 16 1 1 13 to 16
17 to 20 1 4 17 to 20 1 1 17 to 20
21 to 24 1 4 21 to 24 1 1 21 to 24
25 to 28 1 4 25 to 28 1 1 25 to 28
29 to 32 1 4 29 to 32 1 1 29 to 32
33 to 36 – – – 1 4 33 to 36
37 to 40 – – – 1 4 37 to 40
41 to 44 – – – 1 4 41 to 44
45 to 48 – – – 1 4 45 to 48
49 to 52 – – – 1 4 49 to 52
53 to 56 – – – 1 4 53 to 56
57 to 60 – – – 1 4 57 to 60
61 to 64 – – – 1 4 61 to 64
No. System signal format
2160P Other than 2160P
Logical box ID Slot number Port number Logical box ID Slot number Port number
1 to 4 1 1 1 to 4 1 1 1 to 4
5 to 8 1 1 9 to 12 1 1 5 to 8
9 to 12 1 4 17 to 20 1 1 17 to 20
13 to 16 1 4 25 to 28 1 1 21 to 24
17 to 20 – – – 1 4 33 to 36
21 to 24 – – – 1 4 37 to 40
25 to 28 – – – 1 4 49 to 52
29 to 32 – – – 1 4 53 to 56
33 to 36 – – – – – –
37 to 40 – – – – – –
41 to 44 – – – – – –
45 to 48 – – – – – –
49 to 52 – – – – – –
53 to 56 – – – – – –
57 to 60 – – – – – –
61 to 64 – – – – – –
