Sony ICP-X1224

508
3M/E box configuration
3M/E box + cross-point box configuration
No. System signal format
2160P
Logical box ID Slot number Port number
1 to 4 1 1 1 to 4
5 to 8 1 1 9 to 12
9 to 12 1 4 17 to 20
13 to 16 1 4 25 to 28
17 to 20 2 1 33 to 36
21 to 24 2 1 41 to 44
25 to 28 2 4 49 to 52
29 to 32 2 4 57 to 60
33 to 36 3 1 65 to 68
37 to 40 3 1 73 to 76
41 to 44 3 4 81 to 84
45 to 48 3 4 89 to 92
49 to 52 – – –
53 to 56 – – –
57 to 60 – – –
61 to 64 – – –
No. System signal format
2160P
Logical box ID Slot number Port number
1 to 4 1 1 1 to 4
5 to 8 1 1 9 to 12
9 to 12 1 4 17 to 20
13 to 16 1 4 25 to 28
17 to 20 2 1 33 to 36
21 to 24 2 1 41 to 44
25 to 28 2 4 49 to 52
29 to 32 2 4 57 to 60
33 to 36 3 1 65 to 68
37 to 40 3 1 73 to 76
41 to 44 3 4 81 to 84
45 to 48 3 4 89 to 92
49 to 52 – – –
53 to 56 – – –
57 to 60 – – –
61 to 64 – – –
