54
Mode selection buttons
Channel selection buttons
• When multiple channels are selected, the first selected
but
ton becomes the reference, and is lit green.
Subsequent selected buttons are lit amber.
• [CH1] to [CH8] and [K1RSZ] to [K8RSZ] share the
same bu
ttons.
b Op
eration buttons (assignable buttons)
You can assign buttons for use in each operation mode in
th
e Home > Setup > Panel > Module > Button Assign
menu (19104.21).
For details about assigning buttons, see “Assigning
Control Panel Buttons” (page 402).
Resizer operation mode
This mode is used for two-dimensional transform
operat
ions on images using a resizer.
For details about resizer operations, see “Resizer”
(page 137).
Function
name
Button name Description
Menu MENU • Switches to menu
pa
rameter operation
mode.
• You can adjust
p
arameters (numbers 1
to 3) of the currently
displayed menu using
the trackball and Z-ring.
• Press the [MENU]
b
utton twice, turning it
on green, to fix the
target of the trackball
and Z-ring to the
parameter currently
being adjusted.
Run Control RUN CTRL • Switches to run control
o
peration mode.
• Enables operation of
th
e currently recalled
effect timeline using the
Z-ring.
M/E-1 to
M/E-5
P/P
M/E1 to M/E5
P/P
• Switches to resizer
o
peration mode.
• The first selected
button becomes the
reference, and is lit
green. Subsequent
selected buttons are lit
amber.
DME DME Switches to three-
di
mensional transform
operation mode.
Device DEV Switches to device/frame
me
mory/clip player
operation mode.
Function
name
Button name Description
Channel 1 to
C
hannel 12
CH1 to CH12 CH1 to CH4:
Selects the target DME
c
hannel in three-
dimensional transform
operation mode.
CH1 to CH12:
Selects the target device
i
n device/frame memory/
clip player operation
mode.
K1 Resizer to
K8 Resizer
K1RSZ to
K8RSZ
Selects the target resizer
i
n resizer operation mode.
FM 1 Clip to
FM 16 Clip
FM1 CLIP to
FM1
6 CLIP
Selects the target frame
memory output channel in
device/frame memory/clip
player operation mode.
Clip Player 1
to Clip Player
4
CLIP1 to
CL
IP4
Selects the target clip
player output channel in
device/frame memory/clip
player operation mode.
Notes
Function
name
Button name Description
Aspect/
Pers
pective
ASP PERS Adjusts the aspect ratio of
a key using the trackball
or Z-ring.
Location Size LOC SIZE • Moves a key using the
trac
kball.
• Scales a key (shrink/
ma
gnify) using the
Z-ring.
Rotation ROT • Rotates a key using the
trac
kball.
• Adjusts the perspective
of a key using the
Z-ring.
Shift SHIFT Used in combination with
the
[CTR], [CLR WORK
BUFR], and [BDR/CROP]
buttons.
Function
name
Button name Description
