— 67 —
KP- 43T85T / 53SV85T / 61SV85T
SECTION 7: ELECTRICAL PARTS LIST
*
Items marked with an asterisk are not stocked since they are
seldom required for routine service. Expect some delay when
ordering these components.
RESISTORS
• All resistors are in ohms
• F : nonfl ammable
• All variable and adjustable resistors
have characteristic curve B, unless
otherwise noted.
REF.NO. PART NO. DESCRIPTION VALUES
The components in this manual identifi ed by the following
symbol: indicate parts that have been carefully factory-
selected to satisfy regulations regarding X-ray radiation for
each set.
Should replacement be required for one of these components,
replace only with the value originally used.
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es per un trame et
une marque
!
sont critiques pour la securite.
Ne les remplacer que par une piece portant le
numero specifi e.
When ordering parts by reference
number, please include the board name.
REF.NO. PART NO. DESCRIPTION VALUES
CR
* A-1331-922-A CR BOARD, MOUNTED
4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C701 1-104-570-11 CERAMIC 0.001µF 10% 2KV
C703 1-126-947-11 ELECT 47µF 20% 25V
C706 1-102-114-00 CERAMIC 470pF 10% 50V
C708 1-102-113-00 CERAMIC 390pF 10% 50V
C709 1-101-880-00 CERAMIC 47pF 5% 50V
C710 1-162-115-00 CERAMIC 330pF 10% 2KV
C711 1-161-830-00 CERAMIC .0047µF 500V
C712 1-107-662-11 ELECT 22µF 20% 250V
CONNECTOR
* CN701 1-564-507-11 PLUG,CONNECTOR 4P
* CN702 1-564-512-11 PLUG,CONNECTOR 9P
CN703 1-785-879-11 CONNECTOR, ONE TOUCH
!
CN704 1-251-182-11 SOCKET, CRT
CN705 1-695-915-11 TAB (CONTACT)
CN706 1-695-915-11 TAB (CONTACT)
DIODE
D705 8-719-991-33 DIODE 1SS133T-77
D706 8-719-991-33 DIODE 1SS133T-77
D707 8-719-991-33 DIODE 1SS133T-77
D708 8-719-991-33 DIODE 1SS133T-77
D709 8-719-991-33 DIODE 1SS133T-77
COIL
L701 1-414-188-41 INDUCTOR 68µH
L702 1-412-911-11 FERRITE 0µH
NEON LAMP
NL701 1-517-778-21 LAMP, NEON
TRANSISTOR
Q704 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
Q705 8-729-326-11 TRANSISTOR 2SC3271F-N
Q706 8-729-200-17 TRANSISTOR 2SA1091O-TPE2
RESISTOR
R701 1-219-743-11 CARBON 100 5% 1/2W
R702 1-260-132-11 CARBON 560K 5% 1/2W
R703 1-216-486-00 METAL OXIDE 8.2K 5% 3W
R704 1-215-476-00 METAL 200K 1% 1/4W
R711 1-247-807-31 CARBON 100 5% 1/4W
R712 1-249-404-00 CARBON 82 5% 1/4W
R713 1-216-486-00 METAL OXIDE 8.2K 5% 3W
R714 1-249-393-11 CARBON 10 5% 1/4W
R715 1-249-419-11 CARBON 1.5K 5% 1/4W
R718 1-260-133-11 CARBON 680K 5% 1/2W
R719 1-249-425-11 CARBON 4.7K 5% 1/4W
R720 1-260-328-11 CARBON 1K 5% 1/2W
R721 1-260-328-11 CARBON 1K 5% 1/2W
R722 1-260-087-11 CARBON 100 5% 1/2W
R723 1-412-911-11 FERRITE 0µH
SPARK GAP
SG701 1-519-422-11 GAP, SPARK
SG702 1-517-729-31 GAP, SPARK
CR
