– 2 –– 2 –
KP-44PS2/44PS2U/51PS2
RM-903
CAUTION
SHORT CIRCUIT THE ANODE OF HTE PICTURE TUBE
AND THE ANODE CAP TO THE METAL CHASSIS, CRT
SHIELD, OR CARBON PAINTED ON THE CRT, AFTER
REMOVING THE ANODE.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY SHADING AND MARK
! ON THE SCHEMATIC DIAGRAMS, EXPLODED
VIEWS AND IN THE PARTS LIST ARE CRITICAL TO
SAFE OPERATION. REPLACE THESE COMPONENTS
WITH SONY PARTS WHOSE PART NUMBERS AP-
PEAR AS SHOWN IN THIS MANUAL OR IN SUPPLE-
MENTS PUBLISHED BY SONY.
SPECIFICATIONS
Design and specifications are subject to change without notice.
TV system
B/G/H, D/K, I, L
Colour system
PAL, SECAM
NTSC 3.58, 4.43 (only Video In)
Channel coverage
VHF: E2-E12
UHF: E21-E69
CATV: S1-S20
HYPER: S21-S41
D/K: R1-R12, R21-R69
I: UHF B21-B69
L: F2-F10, B-Q, F21-F69
Projected picture size
KP-44PS2/44PS2U:
44 inches (approx. 112 measured diagonally).
KP-51PS2:
51 inches (approx. 130 measured diagonally).
Rear Terminals
• Centre speaker input terminals (2
terminals)
• (L, R) audio outputs (phono jacks)
• i1/ 21-pin Euro connector (CENELEC
standard)
including audio/video input, RGB
input,
TV audio/video output.
• i2/r 2 21-pin Euro connector (CENELEC
(SMARTLINK)
standard) including audio/video
input, S video input,
selectable audio/video output and
Smartlink interface.
• i3/r 3 21-pin Euro connector (CENELEC
standard)
including audio/video input, S video
input,
audio/video output (monitor out).
Front Terminals
r 4 S video input - 4 pin DIN
t 4 video input - phono jack
4 audio inputs - phono jacks
Headphones jack - minijack stereo
C
Sound output
2 x 30 W (music power)
2 x 15 W (RMS)
Centre SP input
30 W (RMS) (using as the centre speaker)
Power consumption
225 W
Standby Power consumption
< 0.7 W
Dimensions (w x h x d)
KP-44PS2/44PS2U: Approx. 1100 x 1161 x 543 mm
KP-51PS2: Approx. 1256 x 1264 x 633 mm
Weight
KP-44PS2/44PS2U: Approx. 87 kg
KP-51PS2: Approx. 97 kg
Accessories supplied
1 Remote Control (RM-903)
2 Batteries (IEC designated)
Other features
DRC 100 Hz picture
Digital Comb filter (High resolution)
TELETEXT, Fastext, TOPtext (2000 page TEXT memory)
NexTView
NICAM
Sleep Timer
Smartlink
Digital Noise detection
Graphic Equaliser
Personal ID
Auto Format
