Sony KP-44PS2 - Control Panel Block Removal; Resistor Assembly (Focus Pack) Removal

– 22 –
KP-44PS2/44PS2U/51PS2
RM-903
3-4. CONTROL PANEL BLOCK REMOVAL
• KP-44/51
3-5. RESISTOR ASSEMBLY (FOCUS PACK) REMOVAL
• KP-44/51
3 Control panel block
1 Front cover
block assembly
2 Four screws
(Hexagon head)
3 Resistor assembly
(Focus pack)
2 Screw
(+BVTP 4 x 16)
1 Four screws
(Hexagon head): (KP-44)/
Two screws
(Hexagon head): (KP-51)
