6-8. AUTO CONVERGENCE ERROR CODE LIST
If an error code is displayed after the set has been fully adjusted, correctly, plese check the following items : position, tilt and sizing. If
either of these adjustments are off, even slightli, the auto registration pattern will not hit the four sensors properly. This occurs when the
internal generator patterns is being flashed on the screen for the sensor to read. Therefore, auto registration (called auto convergence)
cannot operate properly causing an error code to be displayed. In order for this function to operate properly, correct position, tilt and
size must be adjusted properly.
ERROR CODE LIST
ERROR
DESCRIPTION REMEDY
CODE
00 No Error
10 Sensor 0 low output Check sensor 0, connection/wiring, circuit, and pattern position
(Is pattern over sensor ?) Adjust “64 VUP” if necessary.
11 Sensor 1 low output Check sensor 1, connection/wiring, circuit, and pattern position
(Is pattern over sensor ?) Adjust “69 HLE” if necessary.
12 Sensor 2 low output Check sensor 2, connection/wiring, circuit, and pattern position
(Is pattern over sensor ?) Adjust “73 HRIV” if necessary.
13 Sensor 3 low output Check sensor 3, connection/wiring, circuit, and pattern position
(Is pattern over sensor ?) Adjust “68 VLOW” if necessary.
20 Sensor 0 high output Check sensor 0 and circuit.
21 Sensor 1 high output Check sensor 1 and circuit.
22 Sensor 2 high output Check sensor 2 and circuit.
23 Sensor 3 high output Check sensor 3 and circuit.
30 V CENT or SKEW adjustment Check “66 VMID” data and check registration condition.
loop overflow
31 H CENT or SKEW adjustment Check “71 HMID” data and check registration condition.
loop overflow
32 H LIN or SIZE adjustment Check “71 HMID” data and check registration condition.
loop overflow
40 V CENT regi data overflow Check “66 VMID” data and confirm V CENT data (all mode) is not near 511.
41 H CENT regi data overflow Check “71 HMID” data and confirm H CENT data (all mode) is not near 511.
42 V SKEW regi data overflow Check “66 VMID” data and confirm V SKEW data (all mode) is not near 511.
43 H SKEW regi data overflow Check “71 HMID” data and confirm H SKEW data (all mode) is not near 511.
44 H LIN regi data overflow Check “71 HMID” data and confirm H CENT data (all mode) is not near 511.
45 H SIZE regi data overflow Check “71 HMID” data and confirm H CENT data (all mode) is not near 511.
50 V CENT regi data overdrow Check “66 VMID” data and confirm V CENT data (all mode) is not near –512.
51 H CENT regi data overdrow Check “71 HMID” data and confirm H CENT data (all mode) is not near –512.
52 V SKEW regi data overdrow Check “66 VMID” data and confirm V SKEW data (all mode) is not near –512.
53 H SKEW regi data overdrow Check “71 HMID” data and confirm H SKEW data (all mode) is not near –512.
54 H LIN regi data overdrow Check “71 HMID” data and confirm H CENT data (all mode) is not near –512.
55 H SIZE regi data overdrow Check “71 HMID” data and confirm H CENT data (all mode) is not near –512.
60 H or V CENT offset overflow Check “71 HMID” data and check “66 VMID” data.
61 H or V SKEW offset overflow Check SKEW adjustment.
62 H SiZE or LIN offset overflow Check “71 HMID” data, check “66 VMID” data and check SIZE and LIN adjustment.
70 H or V CENT offset overdrow Check “71 HMID” data and check “66 VMID” data.
71 H or V SKEW offset overdrow Check SKEW adjustment.
72 H SIZE or LIN offset overdrow Check “71 HMID” data, check “66 VMID” data and check SIZE and LIN adjustment.
0 : UPPER SENSOR
1 : LEFT SENSOR
2 : RIGHT SENSOR
3 : LOWER SENSOR
SCREEN
0
3
12
[SENSOR POSITION]
