Sony KP-44PS2 - 9 Electrical Parts List

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
– 155 –
KP-44PS2/44PS2U/51PS2
RM-903
NOTE:
REF.NO. PART NO. DESCRIPTION REMARK
SECTION 9
ELECTRICAL PARTS LIST
REF.NO. PART NO. DESCRIPTION REMARK
The components identified by [ in this
manual have been carefully factory-
selected for each set in order to satisfy
regulations regarding X-ray radiation.
Should replacement be required, replace
only with the value originally used.
• All variable and adjustable resistors have
characteristic curve B, unless otherwise
noted.
RESISTORS
• All resistors are in ohms
• F : nonflammable
* A-1372-922-A HA BOARD, COMPLETE
*****************************
<CAPACITOR>
C3101 1-126-157-11 ELECT 10µF 20% 16V
C3102 1-164-346-11 CERAMIC CHIP 1µF 16V
<CONNECTOR>
CN3101 *1-564-508-11 PLUG, CONNECTOR 5P
CN3102 *1-764-333-11 PLUG, CONNECTOR 10P
CN3103 *1-695-292-11 PIN, CONNECTOR (POWER)
CN3104 *1-580-689-11 PIN, CONNECTOR (PC BOARD) 4P
<DIODE>
D3102 8-719-992-06 DIODE SLA-580LT3F (STANDBY)
<IC>
IC3101 8-742-200-20 HYB IC SBX3081-11
<TRANSISTOR>
Q3101 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q3102 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q3103 8-729-106-68 TRANSISTOR 2SD1615A-GP
<RESISTOR>
R3101 1-216-041-00 RES-CHIP 470 5% 1/10W
R3103 1-216-295-91 SHORT 0
R3104 1-216-295-91 SHORT 0
R3105 1-216-037-00 RES-CHIP 330 5% 1/10W
R3106 1-216-295-91 SHORT 0
R3107 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3108 1-216-073-91 RES-CHIP 10K 5% 1/10W
R3109 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3110 1-249-393-11 CARBON 10 5% 1/4W
<SWITCH>
S3101 ! 1-571-433-31 SWITCH, PUSH (AC POWER) (POWER)
*******************************************************************************
* A-1372-923-A HB BOARD, COMPLETE
*****************************
<CAPACITOR>
C3503 1-163-037-11 CERAMIC CHIP 0.022µF 10% 50V
C3504 1-163-037-11 CERAMIC CHIP 0.022µF 10% 50V
<CONNECTOR>
CN3501 * 1-564-526-11 PLUG, CONNECTOR 11P
CN3502 * 1-564-520-11 PLUG, CONNECTOR 5P
<DIODE>
D3501 8-719-914-43 DIODE DAN202K
D3502 8-719-914-43 DIODE DAN202K
<JACK>
J3501 1-568-807-21 TERMINAL BLOCK, (S) 4P (AV 4)
J3502 1-691-293-11 JACK (HEAD PHONE)
<COIL>
L3501 1-414-189-31 INDUCTOR 100µH
L3502 1-414-189-31 INDUCTOR 100µH
<RESISTOR>
R3501 1-216-025-00 RES-CHIP 100 5% 1/10W
R3502 1-216-025-00 RES-CHIP 100 5% 1/10W
R3503 1-216-033-00 RES-CHIP 220 5% 1/10W
R3504 1-216-033-00 RES-CHIP 220 5% 1/10W
R3505 1-216-033-00 RES-CHIP 220 5% 1/10W
R3506 1-216-033-00 RES-CHIP 220 5% 1/10W
*******************************************************************************
HA HB
• Items marked " * " are not stocked since
they are seldom required for routine
service. Some delay should be anticipated
when ordering these items.
• CAPACITORS
PF : µµF
• There are some cases the reference
number on one board overlaps on the
other board. Therefore, when ordering
parts by the reference number, please
include the board name.
When indicating parts by reference
number, please include the board name.
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
