1. Notes to Users
Read all instructions carefully before use.
Save this manual for future references.
1-1. General precautions
When using Sony Manufacturing Systems Corporation
products, observe the following general precautions along
with those given specifically in this manual to ensure proper
use of the products.
. Before and during operations, be sure to check that our
products function properly.
. Provide adequate safety measures to prevent damage in
case our products Should develop a malfunction.
. Use outside indicated specifications or purposes and
modification of our products will void any warranty of the
functions and performance as specified for our products.
. When using our products in combination with other
equipment, the functions and performance as noted in
this manual may not be attained, depending upon the
operating environmental conditions. Make a through
study of the compatibility in advance.
Contents
1. Notes to Users ........................................................... 1
1-1. General precautions .......................................... 1
1-2. Precautions........................................................ 2
1-3. Installation ......................................................... 2
2. Introduction ................................................................ 3
3. Operation ................................................................... 4
3-1. Name of each part ............................................. 4
3-2. Resolution and output phase difference ............ 5
3-2-1. Setting resolution ........................................ 7
3-2-2. Setting the 1/2 division function .................. 7
3-2-3. Output phase difference ............................. 8
3-2-4. Direction switching ...................................... 8
3-3. Using the reference point .................................. 9
3-4. Setting the reference point ................................ 10
3-5. Maximum Response Speed .............................. 11
3-6. Alarm signal ....................................................... 11
3-7. Supplying the power .......................................... 12
3-8. Mounting the Interpolator................................... 12
3-9. Supplied ferrite core .......................................... 13
4. Output Connector ....................................................... 14
5. Specifications ............................................................ 16
6. Dimensions ................................................................ 18
