2. Introduction
This product is a 1-axis interpolator with modular design for
industrial machines. When it is used in combination with the
optionally available PL25 head unit and SL110 or SL130
scale unit or with the PL60 head with cable and SL331
scale unit, it outputs quadrature A/B signals with a
resolution from 2 to 100 um.
System configuration
Features
. Multiaxis configuration is readily available thanks to the
modular design.
. The MJ100 operates on 4.5 to 6 V DC power supply.
. The MJ110 operates on 11 to 31 V DC power supply.
. An A/B phase synchronized reference point signal can be
output by connecting the optionally available SET-P16-1.
. Reference point signals in synchronization with the
quadrature A/B signals can be output.
. Output signals include the A/B phase signal, U/V/W
phase signals (MJ100 only), reference point signal, and
alarm signal. The MJ100 uses voltage-differential line
driver output that complies with RS-422 standard
(MC34C87 or equivalent), while the MJ110 uses open
collector output.
. The compact miniature DIN connector used for the read
head can be easily led through pipes.
MJ100
PL25
SL110/SL130
MJ110
PL60
SL331
Head unit
Scale unit
Interpolator unit
