Separately Sold Accessories
. Extension cables for the head
Model Cable Length
CE08-1 1 m
CE08-3 3 m
CE08-5 5 m
CE08-10 10 m
CE08-15 15 m
. Extension cables for the reference point
Model Cable Length
CE15-3 3 m
CE15-5 5 m
CE15-10 10 m
CE15-15 15 m
. Cables with output connector
Model Cable Length
CE16-3 3 m
CE16-6 6 m
. Output connector
MZ2
Correlation between phase difference and response speed
Phase difference (µs)
Note
1. The minimum phase difference is represented by the lowest
value among the interpolator outputs, but it may increase due to
the effects of the scale travel speed, output cable length, line
capacitance, etc.
2. The minimum phase difference varies due to the effects of the
output cable length, line capacitance, receiver load, etc.
3. The maximum response speed has the correlation with the
phase difference which is shown in the graph below.
Correlation between phase difference and response speed
Fig. 5-1
1000
10000
50 um10 um5 um
10 1001
0.1
1
10
100
Response speed (m/min)
Rasolution
