Sony NXCAM HXR-NX80 User Manual

122
DISPLAY OUTPUT
LCD PANEL, ALL
OUTPUT
Sets the output to display information, such as
the timecode.
You can select to display information on the
LCD screen only, or output the information to
the VIDEO OUT, HDMI OUT jacks and the
LCD screen. Zebra, peaking and the frame on
the face are also output.
• During marker display, only the timecode,
zebra, peaking, and face detection indicators
are output, even if [DISPLAY OUTPUT] is
set to [ALL OUTPUT].
TC/UB SET menu
TC/UB SET
Menu item Sub-items/Settings Description
TC/UB DISPLAY
TC, U-BIT Switches the display to timecode or user bits.
TC PRESET
PRESET, RESET Sets the timecode (p. 58).
UB PRESET
PRESET, RESET Sets the user bits (p. 59).
TC FORMAT
DF, NDF Switches the timecode recording method when
[60i] is selected. The timecode is fixed to
[NDF] when [50i] is selected.
DF: Records the timecode in drop frame.
NDF: Records the timecode in non-drop frame.
• The timecode is also fixed to [NDF] (when
[60i] is selected) when the frame rate is set to
24 in [REC FORMAT].
• Drop-frame
Timecode is based on 30 frames per second;
however, gaps in the actual time occur during
extended periods of recording as the actual
frame frequency of NTSC image signals is
29.97 frames per second. Drop frame corrects
this gap to make timecode and actual time
equal. In drop frame, the first 2 frame
numbers are removed every minute except in
every tenth minute. Timecode without this
correction is called non-drop frame.
DISPLAY SET
Menu item Sub-items/Settings Description
Menu items (Continued)

Sony NXCAM HXR-NX80 Specifications

General

Lens	ZEISS Vario-Sonnar T*
Optical Zoom	12x
ND Filter	Clear, 1/4, 1/16, 1/64
Image Stabilization	Optical SteadyShot with Active Mode
Maximum Resolution	3840 x 2160 (4K)
Microphone	Built-in stereo microphone
Memory Card Slots	Dual SD card slots
Effective Pixels	14.2MP
Digital Zoom	48x
Focal Length	9.3 - 111.6 mm
Aperture	f/2.8 - f/4.5
Minimum Focusing Distance	1 cm (Wide)
Recording Format	XAVC S, AVCHD
Frame Rate	Up to 120fps (HD)
Audio Recording	Linear PCM 2ch, Dolby Digital 2ch
LCD Screen	3.5-inch (1.56 million dots) touchscreen LCD
Viewfinder	0.39-inch type OLED, approx. 2.36 million dots
Battery	NP-FV70A
Dimensions	89.5 x
Connectivity	HDMI, USB, Wi-Fi, NFC
