Recording
L: AUDIO LEVEL (CH2) dial
Wind noise reduction switches
G: LOW CUT (INPUT1) switch
M: LOW CUT (INPUT2) switch
When using a microphone with XLR-type
connector (sold separately) or external
audio device (such as a mixer), configure
the settings as described below.
1 Select the audio input source.
• Set the INPUT1/INPUT2 (LINE/MIC/
MIC+48V) switch (D or F) based
on the device connected to INPUT1
jack A/INPUT2 jack B.
b Notes
• If the switch is set to MIC+48V and you connect
a device that is not compatible with +48V
power, it may damage the connected device.
Check the switch before connecting the device.
• To prevent unwanted noise when no audio
device is connected to the INPUT1 or INPUT2
jack, set the INPUT1/INPUT2 (LINE/MIC/
MIC+48V) switch (D or F) to LINE.
2 Set the microphone input level.
When the INPUT1/INPUT2 (LINE/
MIC/MIC+48V) switch (D or F) is
set to MIC or MIC+48V, the input level
can be set using the ATT (INPUT1/
INPUT2) switch (C or E). Adjust the
setting based on the sensitivity of the
microphone.
ATT 0dB: –60dBu
ATT 10dB: –50dBu
ATT 20dB: –40dBu
b Note
• The input level is fixed to +4dBu when the
INPUT1/INPUT2 (LINE/MIC/MIC+48V)
switch (D or F) is set to LINE. The input
level does not change, even if you change the
ATT switch setting.
3 Select the channel to record.
With the REC CH SELECT (INPUT1)
switch H, select the channel to record.
z Tip
• When using a stereo microphone with two XLR
(3-pin) plugs, connect the INPUT1 jack A to
the left channel, connect the INPUT2 jack B to
the right channel, and set the REC CH SELECT
(INPUT1) switch H to CH1.
You can record audio with a Multi Interface
Shoe-compatible microphone.
1 Connect the Multi Interface Shoe
compatible microphone (sold
separately) to the Multi Interface
Shoe.
Connected device Switch position
External audio device (such
as mixer)
LINE
Dynamic microphone or
microphone with built-in
battery
MIC
+48V powered (phantom
power) microphone
MIC+48V
REC CH SELECT
(INPUT1) switch
setting
Sound recorded to CH1 and
CH2
CH1•CH2
INPUT1 CH1
CH2
CH1
INPUT1
INPUT2
CH1
CH2
Recording sound from a Multi
Interface Shoe compatible
microphone (sold separately)
Continued ,
To Next Page
