Sony NXCAM HXR-NX80 User Manual

48
Using Direct Menu
Direct Menu allows you to change settings
directly while recording using the v/V/b/
B/SET buttons.
The following items can be configured.
• Focus value (p. 35)
• AE shift level value (p. 104)
• Iris value (p. 43)
• ISO sensitivity/gain value (p. 44)
• Shutter speed value (p. 44)
• White balance value (p. 46)
You can assign this function to an ASSIGN
button.
For details about function assignment
operation to an ASSIGN button, see
“Assigning functions to the ASSIGN
buttons” (p. 64).
1 Press the ASSIGN button to
which Direct Menu is assigned.
After entering Direct Menu mode, a
cursor (underline) is displayed for items
along the bottom of the LCD screen.
• Orange cursor indicates the selected
item.
• White cursor indicates selectable
items.
For example, the iris value 3 is
selected in the following diagram.
A Focus value
B AE shift level value
C Iris value
D ISO sensitivity/gain value
E Shutter speed value
F White balance value
2 Move the v/V/b/B/SET button left/
right to move the orange cursor
to select the target item to set.
3 When (auto) appears for the
item to set, moving the v/V/b/B/
SET button up/down clears the
mark.
4 Press the v /V/b/B/SET button to
apply the setting.
The set value is highlighted in reverse
black and white, allowing you to change
the value.
The following diagram shows an
example of changing the shutter speed
value.
v/V/b/B/SET
buttons
Orange cursor
Shutter speed value

Sony NXCAM HXR-NX80 Specifications

General

Lens	ZEISS Vario-Sonnar T*
Optical Zoom	12x
ND Filter	Clear, 1/4, 1/16, 1/64
Image Stabilization	Optical SteadyShot with Active Mode
Maximum Resolution	3840 x 2160 (4K)
Microphone	Built-in stereo microphone
Memory Card Slots	Dual SD card slots
Effective Pixels	14.2MP
Digital Zoom	48x
Focal Length	9.3 - 111.6 mm
Aperture	f/2.8 - f/4.5
Minimum Focusing Distance	1 cm (Wide)
Recording Format	XAVC S, AVCHD
Frame Rate	Up to 120fps (HD)
Audio Recording	Linear PCM 2ch, Dolby Digital 2ch
LCD Screen	3.5-inch (1.56 million dots) touchscreen LCD
Viewfinder	0.39-inch type OLED, approx. 2.36 million dots
Battery	NP-FV70A
Dimensions	89.5 x
Connectivity	HDMI, USB, Wi-Fi, NFC
