Sony NXCAM HXR-NX80 User Manual

83
Using Network Functions
Using the streaming
function (STREAMING)
You can connect the camcorder to a
network and stream a movie in real-time to
external devices.
b Note
• Camcorder streaming uses MPEG2-TS/UDP
transport stream. To view the streamed video
and audio, use devices that supports this
transport stream format. For details, refer to the
instruction manuals of each device.
There are limitations on the size of the
original file movie and the streaming
movie.
For details, see “Streaming, RTMP/
RTMPS, and USTREAM supported
formats” (p. 153).
You configure streaming settings and
register them using PRESET beforehand to
distribute a stream using those settings.
The following items can be configured.
SIZE
Select the image size for streaming.
– 1280×720
– 640×360
z Tip
• Select a size of “640×360” for increased
streaming distribution stability.
DESTINATION SET
Configure the streaming distribution
destination.
– Host Name: IP address or host name of
the receiver
– Port: Port number used for streaming on
the receiver
Streaming formats
Configuring streaming (preset
registration)
1 Configure the basic network
settings (p. 77, 82).
2 Press the MENU button.
3 Select (NETWORK SET) t
[STREAMING] t desired
PRESET number t configuration
item.
4 Select/set the setting value.
5 Press the MENU button to return
to the shooting screen.
You can distribute a stream of the movie,
while shooting, using the connected
network.
1 Check that the network
connection settings are
successful (p. 77, 82).
2 Press the MENU button.
3 Select (NETWORK SET) t
[STREAMING] t [EXECUTE] t
network connection method.
• The network connection starts.
Streaming distribution
Continued ,

Sony NXCAM HXR-NX80 Specifications

General

Lens	ZEISS Vario-Sonnar T*
Optical Zoom	12x
ND Filter	Clear, 1/4, 1/16, 1/64
Image Stabilization	Optical SteadyShot with Active Mode
Maximum Resolution	3840 x 2160 (4K)
Microphone	Built-in stereo microphone
Memory Card Slots	Dual SD card slots
Effective Pixels	14.2MP
Digital Zoom	48x
Focal Length	9.3 - 111.6 mm
Aperture	f/2.8 - f/4.5
Minimum Focusing Distance	1 cm (Wide)
Recording Format	XAVC S, AVCHD
Frame Rate	Up to 120fps (HD)
Audio Recording	Linear PCM 2ch, Dolby Digital 2ch
LCD Screen	3.5-inch (1.56 million dots) touchscreen LCD
Viewfinder	0.39-inch type OLED, approx. 2.36 million dots
Battery	NP-FV70A
Dimensions	89.5 x
Connectivity	HDMI, USB, Wi-Fi, NFC
