Sony NXCAM HXR-NX80 User Manual

41
Recording
Selecting the file format and recording format
Set the file format in (REC/OUT SET)
t [REC SET] t [FILE FORMAT] and
the recording format (bit rate, picture size,
frame rate, scanning method) in (REC/
OUT SET) t [REC SET] t [REC
FORMAT] (p. 111).
You can select the output for the video
signal when recording in XAVC S 4K.
1 Press the MENU button.
2 Select (REC/OUT SET) t
[VIDEO OUT] t [OUTPUT
SELECT] t [4K REC OUTPUT].
3 Select the output destination.
VF/LCD PANEL
Output to viewfinder/LCD screen.
EXTERNAL OUTPUT
Output to an external device.
b Notes
• The [4K REC OUTPUT] settings are enabled
only when the file format is XAVC S 4K.
• The picture being recorded is not displayed on
the viewfinder/LCD screen when [4K REC
OUTPUT] is set to [EXTERNAL OUTPUT].
Also, [NIGHTSHOT LIGHT] is set to [OFF].
• The picture is output to the viewfinder/LCD
screen when recording and streaming, even
when set to [EXTERNAL OUTPUT].
• If recording in XAVC S 4K is started with [4K
REC OUTPUT] set to [EXTERNAL
OUTPUT], then [LCD BRIGHT] is set to
[NORMAL].
• Any one of the following functions can be used
while recording in XAVC S 4K.
– 4K REC OUTPUT
– FACE DETECTION
– Proxy recording
Setting the file format and
recording format
Setting the output destination
when recording in 4K mode

Sony NXCAM HXR-NX80 Specifications

General

Lens	ZEISS Vario-Sonnar T*
Optical Zoom	12x
ND Filter	Clear, 1/4, 1/16, 1/64
Image Stabilization	Optical SteadyShot with Active Mode
Maximum Resolution	3840 x 2160 (4K)
Microphone	Built-in stereo microphone
Memory Card Slots	Dual SD card slots
Effective Pixels	14.2MP
Digital Zoom	48x
Focal Length	9.3 - 111.6 mm
Aperture	f/2.8 - f/4.5
Minimum Focusing Distance	1 cm (Wide)
Recording Format	XAVC S, AVCHD
Frame Rate	Up to 120fps (HD)
Audio Recording	Linear PCM 2ch, Dolby Digital 2ch
LCD Screen	3.5-inch (1.56 million dots) touchscreen LCD
Viewfinder	0.39-inch type OLED, approx. 2.36 million dots
Battery	NP-FV70A
Dimensions	89.5 x
Connectivity	HDMI, USB, Wi-Fi, NFC
