Sony NXCAM HXR-NX80 User Manual

43
Recording
Adjusting the brightness
You can adjust the image brightness by
adjusting the iris, ISO sensitivity/gain or
shutter speed, or by adjusting the light level
with the ND filter E.
b Note
• When you set the AUTO/MANUAL switch F
to AUTO, iris, ISO sensitivity/gain, shutter
speed, and white balance are adjusted
automatically. You cannot adjust them
manually.
1 Set the AUTO/MANUAL switch F
to MANUAL.
2 Press the IRIS button B.
The or next to the iris value
disappears, and the iris value is
highlighted.
3 Turn the MANUAL dial A to
adjust the value.
The light level increases the more that
you open the aperture (decreasing F
value). The light level decreases the
more that you close the aperture
(increasing F value).
To temporarily adjust automatically
Hold the ASSIGN5/IRIS PUSH AUTO
button down.
The iris is adjusted automatically for as
long as you hold the button down.
To adjust automatically
Press the IRIS button B while the iris
value is highlighted.
The iris value disappears or appears
next to the iris value. When AE is fixed,
appears.
Adjusting the iris
Iris value
Continued ,

Sony NXCAM HXR-NX80 Specifications

General

Lens	ZEISS Vario-Sonnar T*
Optical Zoom	12x
ND Filter	Clear, 1/4, 1/16, 1/64
Image Stabilization	Optical SteadyShot with Active Mode
Maximum Resolution	3840 x 2160 (4K)
Microphone	Built-in stereo microphone
Memory Card Slots	Dual SD card slots
Effective Pixels	14.2MP
Digital Zoom	48x
Focal Length	9.3 - 111.6 mm
Aperture	f/2.8 - f/4.5
Minimum Focusing Distance	1 cm (Wide)
Recording Format	XAVC S, AVCHD
Frame Rate	Up to 120fps (HD)
Audio Recording	Linear PCM 2ch, Dolby Digital 2ch
LCD Screen	3.5-inch (1.56 million dots) touchscreen LCD
Viewfinder	0.39-inch type OLED, approx. 2.36 million dots
Battery	NP-FV70A
Dimensions	89.5 x
Connectivity	HDMI, USB, Wi-Fi, NFC
