81
RCD-W10
Pin No.
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204 to 207
208
I/O
—
—
O
I
O
I/O
I/O
I/O
I/O
I/O
O
O
O
O
O
—
Pin Name
DVDD
DVSS
ADCSTBY
AUXTX
DITOUT
TEST3
SBDATA
CLCK
SFSY
SBSY
ZRAS
ZCAS
ZWE
ZOE
RA0 to RA3
DVDD
Description
Power supply +5V (digital)
Ground terminal (digital)
ADC standby signal output
DIT data input Not used (fixed at “L”)
DIT data output
Used as EXTDACEMP input (fixed at “L”)
Sub-code I/F serial data input/output (fixed at “L”)
Sub-code I/F data shift clock input/output (fixed at “L”)
Sub-code I/F frame sync signal input/output (fixed at “L”)
Sub-code I/F block sync signal input/output (fixed at “L”)
Row address strobe signal output to the buffer RAM for audio data delay
Column address strobe signal output to the buffer RAM for audio data delay
Write enable signal output to the buffer RAM for audio data delay
Read enable signal output to the buffer RAM for audio data delay
Address signal output to the buffer RAM for audio data delay
Power supply +3.3V (DRAM I/F)

Sony RCD-W10 Specifications

Power

North American model power requirements	120 V AC, 60 Hz
Mexican model power requirements	120 V AC, 60 Hz
Other models power requirements	110-120/220-240V AC, 50/60 Hz
Power consumption	25 W

Inputs

ANALOG IN impedance	47 kilohms
ANALOG IN rated input	500 mVrms
ANALOG IN minimum input	250 mVrms

Outputs

ANALOG OUT impedance	47 kilohms
ANALOG OUT rated output	2 Vrms
ANALOG OUT load impedance	over 10 kilohms

Weight and Dimensions

dimensions	430 × 108 × 399 mm
RCD-W50C mass	6.8 kg
RCD-W10 mass	6.0 kg
