4-13
SLV-ED1/ED4/ED7/ED8
• Waveforms
1 IC201 4 PB
2 IC201 6 REC
3 IC201 7 PB
4 IC201 !∞ REC
5 IC202 8 REC/PB
7 IC202 5 REC/PB
8 IC202 4 REC/PB
9 IC201 &¶ REC/PB
!º IC201 &¡ REC/PB
6 IC202 1 REC/PB
!™ IC201 %¶ REC/PB
!£ IC201 %£ REC/PB
!¢ IC201 %º PB
!∞ IC201 @§ REC/PB
!¡ IC201 ^º REC
840m Vp-p (H)
400m Vp-p (H)
840m Vp-p (H)
370m Vp-p (H)
REC: 250m Vp-p (H)
PB : 300m Vp-p (H)
REC: 400m Vp-p (H)
PB : 500m Vp-p (H)
360m Vp-p (H)
560m Vp-p (H)
REC: 470m Vp-p (H)
PB : 260m Vp-p (H)
440m Vp-p (H)
1 Vp-p (H)
2.2 Vp-p (H)
5 Vp-p (H)
640m Vp-p (H)
1.1 Vp-p (3.58 MHz)
