Sony STR-DA6400ES - Page 125

STR-DA6400ES
125
SB
IC2208 XL (XOUT)
1 V/DIV, 20 ns/DIV
4 Vp-p
40.7 ns
ZE
IC5208 UK (XOUT)
1 V/DIV, 50 ns/DIV
80 ns
3.5 Vp-p
ZB
IC5002 A2 (XTAL)
1 V/DIV, 50 ns/DIV
81.4 ns
3 Vp-p
ZT
IC5202 A2 (XTAL)
1 V/DIV, 20 ns/DIV
40 ns
2.4 Vp-p
FB
IC3855 FK (CR/B)
(Color bar)
200 mV/DIV, 20 μs/DIV
H
0.6 Vp-p
FT
IC3855 FL (CB/R)
(Color bar)
200 mV/DIV, 20 μs/DIV
H
0.6 Vp-p
FE
IC3855 FM (Y/G)
(Color bar)
500 mV/DIV, 20 μs/DIV
H
1 Vp-p
FG
IC3855 SG (V)
(Color bar)
500 mV/DIV, 20 μs/DIV
1.2 Vp-p
FH
IC3604 [WY (XOUT)
1 V/DIV, 20 ns/DIV
31.1 ns
3.4 Vp-p
FI
IC3511 PG (XTALOUT)
1 V/DIV, 20 ns/DIV
4.5 Vp-p
35.3 ns
FK
IC3610 S (X1)
1 V/DIV, 100 ns/DIV
250 ns
3.2 Vp-p
JB
IC8204 RH (XOUT)
2 V/DIV, 200 ns/DIV
270 ns
3.44 Vp-p
JE
X8003 (OUT)
2 V/DIV, 20 ns/DIV
37.4 ns
4 Vp-p
JT
IC6801 XI (OSCOUT)
2 V/DIV, 20 ns/DIV
22.6 ns
3.2 Vp-p
• Waveforms
– DIGITAL Board –
– DSP Board – – NETWORK Board –
– D VIDEO Board –
