STR-DA6400ES
158
NETWORK BOARD IC8013 PNX1502E/G, 557 (CONNECTED MEDIA PROCESSOR)
Pin No. Pin Name I/O Description
A1 JTAG_TDI I JTAG test data signal input terminal Not used
A2 VCCP - Power supply terminal (+3.3V)
A3, A4
CLOCK02/BOOT_
MODE02, CLOCK03/
BOOT_MODE03
- Not used
A5 VSSA - Ground terminal
A6 SPDI I Not used
A7 CLOCK04 O UART selection signal output terminal
A8 CLOCK05 O Relay drive signal (for main power) output terminal "H": relay on
A9 VSS - Ground terminal
A10 VCCA - Power supply terminal (+3.3V)
A11 POR_IN_N I Reset signal input terminal
A12 VCCP - Power supply terminal (+3.3V)
A13 VSS - Ground terminal
A14 VSSA - Ground terminal
A15 VCCP - Power supply terminal (+3.3V)
A16 VCCA - Power supply terminal (+3.3V)
A17 VCCP - Power supply terminal (+3.3V)
A18 to A21
FGPO_BUF_SYNC,
VDD_D33, VDD_D00,
VDD_D01
O Not used
A22 to A26
VDO_D05, VDO_D09,
VDO_D14, VDO_D16,
VDO_D17
O Digital video signal output to the D/A converter (for network section)
B1 JTAG_TCK I JTAG test clock signal input terminal Not used
B2 VDD_D34 O Not used
B3
CLOCK01/
BOOT_MODE01
O Emphasis control signal output to the D/A converter (for network section)
B4
CLOCK00/
BOOT_MODE00
O Mutting control signal output terminal
B5 VCCA - Power supply terminal (+3.3V)
B6 VCCP - Power supply terminal (+3.3V)
B7 VSS - Ground terminal
B8 VSSA - Ground terminal
B9 CLOCK06 O Dimmer control signal output terminal for MULTI CHANNEL DECODEING indicator
B10 to B12 VSS - Ground terminal
B13 VSSA - Ground terminal
B14 VCCP - Power supply terminal (+3.3V)
B15, B16 VSSA - Ground terminal
B17 VSS - Ground terminal
B18 to B20
VDD_D32, VDO_CLK2,
VDO_D02
O Not used
B21 to B24
VDO_D06, VDO_D07,
VDO_D11, VDO_D15
O Digital video signal output to the D/A converter (for network section)
B25 VSS - Ground terminal
B26 VDO_D21 O Digital video signal output to the D/A converter (for network section)
C1 to C3
MM_DATA01, MM_
DATA00, MM_DATA15
I/O Two-way data bus with the SD-RAM
C4 VSS - Ground terminal
C5 VSS - Ground terminal
C6 VCCP - Power supply terminal (+3.3V)
C7 RESET_IN_N I Reset signal input terminal
C8 IIC_SDA I/O Two-way data bus with the EEPROM and D/A converter (for network section)
C9, C10 VCCP - Power supply terminal (+3.3V)
C11 VSSA_1.2 - Ground terminal
C12 VCCP - Power supply terminal (+3.3V)
C13 VCCA - Power supply terminal (+3.3V)
