Pin No. Pin Name I/O Description
C14 to
C16
VSS - Ground terminal
C17 FGPO_REC_SYNC O Not used
C18 VCCP - Power supply terminal (+3.3V)
C19 VDO_D03 O Not used
C20 to
C23
VDO_D08, VDO_D10,
VDO_D12, VDO_D18
O Digital video signal output to the D/A converter (for network section)
C24 VCCP - Power supply terminal (+3.3V)
C25 VDO_D22 O Digital video signal output to the D/A converter (for network section)
C26 VDO_D31 O BLANK signal output to the D/A converter (for network section)
D1 MM_DATA03 I/O Two-way data bus with the SD-RAM
D2 VCCM - Power supply terminal (+3.3V)
D3 MM_DATA14 I/O Two-way data bus with the SD-RAM
D4 VCCM - Power supply terminal (+3.3V)
D5 JTAG_TMS I JTAG test mode select signal input terminal Not used
D6 JTAG_TDO O JTAG test data signal output terminal Not used
D7 VCCA - Power supply terminal (+3.3V)
D8 IIC_SCL I/O Two-way clock data bus with the EEPROM and D/A converter (for network section)
D9 XTAL_OUT O System clock input terminal Not used
D10 SYS_RST_OUT_N O
Reset signal output to the ethernet interface, D/A converter (for network section) and parallel
bus/I2C bus converter
D11 XTAL_IN I System clock input terminal (27MHz)
D12, D13 VCCP - Power supply terminal (+3.3V)
D14, D15 VCCA - Power supply terminal (+3.3V)
D16 VDO_D04 O Not used
D17 VDO_D13 O Digital video signal output to the D/A converter (for network section)
D18 VDO_CLK1 O Serial data transfer clock signal output to the D/A converter (for network section)
D19 VDO_D23 O Digital video signal output to the D/A converter (for network section)
D20 to
D22
VDO_D29, VDO_D19,
VDO_D20
O Vertical sync signal output to the D/A converter (for network section)
D23 PCI_SERR_N I/O Two-way data bus with terminal Not used
D24 PCI_GNT_N I/O Two-way data bus with terminal Not used
D25 PCI_GNT_A_N I Interrupt request signal input from the parallel bus/I2C bus converter
D26 PCI_GNT_B_N I Interrupt request signal input terminal Not used
E1 to E4
MM_DATA04, MM_
DATA02, MM_DATA12,
MM_DATA13
I/O Two-way data bus with the SD-RAM
E5 VSS - Ground terminal
E6 VSS - Ground terminal
E7 to E10 VCCP - Power supply terminal (+3.3V)
E11, E12 VSS - Ground terminal
E13 to E16 VCCP - Power supply terminal (+3.3V)
E17, E18 VSS - Ground terminal
E19, E20 VCCP - Power supply terminal (+3.3V)
E21, E22 VSS - Ground terminal
E23 PCI_CLK I System clock input terminal (27MHz)
E24 VDO_AUX O Not used
E25 PCI_SYS_CLK O Not used
E26 VDO_D30 O Horizontal sync signal output to the D/A converter (for network section)
F1 to F3
MM_DATA06, MM_
DATA05, MM_DATA11
I/O Two-way data bus with the SD-RAM
F4, F5 VSS - Ground terminal
F22 VSS - Ground terminal
F23 PCI_REQ_N I/O Two-way data bus with terminal Not used
F24 to F26 VDO_D28 to VDO_D26 O Digital video signal output to the D/A converter (for network section)
G1 MM_DQS1 I/O Two-way data strobe signal with the SD-RAM
G2 VCCM - Power supply terminal (+3.3V)
